Toulon, France 17 October 2019 |
 |
| Toulon, France 17/10/19 |
|
Name |
TATIANA-B |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9406972 |
|
Call sign |
FNOE |
|
Flag |
France |
|
Port of registry |
Martigues |
|
GT |
2.158 t |
|
DWT |
Summer: 3.536 t |
|
NT |
986 t |
|
Length |
89,20 m overall 86,10 m between perpendiculars |
|
Breadth |
13,80 m |
|
Draught |
Max: 5,00 m |
|
Freeboard |
1.707 mm |
|
Depth |
6,45 m |
|
Speed |
Service: 12,5 knots |
|
Built |
2008 |
|
Date of completion |
05/05/2008 |
|
Builder casco |
Vard Braila |
|
Builder completion |
Brevik Construction |
|
Yard number |
110/60 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x Mitsubishi S6U2-MPTK - 4 stroke 6 cylinder 240 x 160 mm combustion engine 2.080 hp / 2.080 kW at 930 rpm Build: 01/2008 Builder: Mitsubishi Heavy Industries, Ltd. General Machiner, Sagamihara - Japan |
|
Propellers |
2x Screw propeller controllable pitch - aft at 280 rpm |
|
Shaft generator |
2x 500 kVA - 400 kW |
|
Generators |
1x Main diesel generatorset 500 kVA - 400 kW - 584 hp |
|
Emergency generator |
1x Diesel generatorset 199 kVA - 159 kW - 270 hp |
|
Bow thruster |
1x 220 kW |
|
Number of cargo tanks |
12 |
|
Total capacity of tanks |
3.500 m³ |
|
Pumps |
12x Cargo pumps each 200 m³/h |
|
Operator |
Maritima / Groupe CFT |
|
Owner |
Compagnie Fluviale De Transport |
|
Registered owner |
Tatiana B SNC |
|
Latest data adjustment |
16 December 2019 |
