Westerschelde 30 December 2019 |
|
Name |
PORTMAN SQUARE |
|
Previous names |
2002 - 2014 Song Lin Wan |
|
Type |
Crude oil tanker - Aframax |
|
IMO-number |
9264570 |
|
Call sign |
D5HK9 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
Previous flags |
2002 - 07/2003 Republic of Panama 07/2003 - 11/2014 Hong Kong - Call sign: VRYD9 |
|
GT |
56.358 t Suez: 58.472 t |
|
DWT |
Summer: 105.965 t Winter: 103.163 t |
|
NT |
32.355 t Suez: 54.567 t |
|
Displacement |
121.803 t |
|
Length |
241,03 m overall 232,00 m between perpendiculars |
|
Breadth |
42,00 m |
|
Draught |
Summer: 14,92 m Winter: 14,61 m |
|
Depth |
21,20 m moulded |
|
Speed |
Max: 15,6 knots Service: 14,5 knots |
|
Built |
2002 |
|
Keel laid |
13/03/2002 |
|
Date of completion |
27/11/2002 |
|
Builder |
Namura Shipbuilding Co., Ltd. Osaka Japan |
|
Yard number |
238 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight components |
9 |
|
Continuous decks |
1 |
|
Main engine |
1x Hitachi/MAN-B&W 6S60MC - 2 stroke single acting 6 cylinder 600 x 2.292 mm combustion engine 11.770 kW / 15.992 hp at 101,0 rpm Build: 2002 Builder: Hitachi Zosen Corporation Ariake Machinery Works, Nagasu Ariake - Japan |
|
Propellers |
1x Screw propeller solid - aft at 101,0 rpm |
|
Boilers |
1x CHR 220,00 m² 1x CHO 247,00 m² |
|
Generators |
3x Yanmar main diesel generatorsets each 725 kVA - 580 kW - 897 hp |
|
Emergency generator |
1x Diesel generatorset 135 kVA - 108 kW - 186 hp |
|
Number of pumps |
3x Cargo pumps each 2.500 m³/h |
|
Tank capacities |
Fuel: 2.869,8 m³ |
|
Crew size |
32 |
|
Manager |
Zodiac Maritme Ltd. 5th Floor, Portman House 2 Portman Street London, W1H 6DU United kingdom |
|
Registered owner |
Bizand Maritime Inc. |
|
Renamed |
2020 Themis Republic of Panama, Panama City - call sign: 3EFU8 Owner: Themis Ltd., Marshall Islands - Care of Moonlight Shipping Pte Ltd. - Republic of Singapore Manager: Moonlight Shipping Pte Ltd., Republic of Singapore |
|
Latest data adjustment |
19 March 2021 |
