Westerschelde 05 July 2020 |
 |
|
| Westerschelde 30/03/20 | |
|
Name |
PILSUM |
|
Previous names |
1993 Build as: Pilsum 03/1993 - 12/1996 Saar Rotterdam 12/1996 - 01/1998 Pilsum 01/1998 - 07/2002 Heiko B |
|
Type |
General cargo ship - Equipped for carriage of containers |
|
IMO-number |
9015448 |
|
Call sign |
V2AH9 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John’s |
|
GT |
1.662 t |
|
DWT |
Summer: 2.372 t |
|
DWCC |
Summer: 2.200 t Winter: 2.150 t |
|
NT |
810 t |
|
Number of 20ft containers |
80 |
|
Length |
81,59 m overall 77,50 m between perpendiculars |
|
Breadth |
11,30 m extreme |
|
Draught |
Summer: 4,34 m Winter: 4,25 m |
|
Air draft |
19,60 m full ballast 17,50 m loaded |
|
Depth |
5,52 m moulded |
|
Speed |
Laden: 8,5 knots Ballast: 9,0 knots |
|
Built |
1993 |
|
Keel laid |
19/05/1992 |
|
Launch date |
14/08/1992 |
|
Date of completion |
01/03/1993 |
|
Builder |
Rosslauer Schiffswerft GmbH Rosslau/Elbe Germany |
|
Yard number |
243 |
|
Hull material |
Steel |
|
Movable bulkheads |
2x Units movable, various positions |
|
Continuous decks |
1 |
|
Main engine |
1x SBV 6M628 - 6 cylinder combustion engine 600 kW / 815 hp Builder: Deutz MWM diesel |
|
Propellers |
1x Fixed propeller 4 blades - Diameter 2.400 m |
|
Boilers |
1x Auxiliary boiler, oil/gas fired |
|
Generators |
2x Deutz MWM D234V8 main diesel generatorsets each 104 kW |
|
Emergency & harbour gen. |
1x Deutz F5L413FR diesel generatorset 68 KW |
|
Bow thruster |
140 kW |
|
Number of holds |
1 52,00 x 9,00 x 6,53 m 51,40 x 9,00 x 6,53 m Incl. bulkheads |
|
Cargo hold capacity |
3.074 m³ / 106,.000 ft³ |
|
Hold ventilation |
Mechanical |
|
Number of hatches |
1 52,25 x 9,25 m |
|
Hatch type |
Kvaerner folding type |
|
Max permitted loads |
Tanktop: 12,0 t/m² Deck: 1,52 t/m² |
|
Tank capacities |
Ballast: 1.200,7 m³ Gas oil: 95 t |
|
Anchor equipment |
Length: 385,00 m Diameter: 30 mm |
|
Manager |
Reederei Erwin Strahlmann GmbH & Co. KG Schleusenstraße 10 25541 Brunsbüttel Germany |
|
Operator |
R.E.S Chartering GmbH Hamburg Germany |
|
Registered owner |
Roland Coastal Marine GmbH & Co., KG 25541 Brunsbüttel Germany |
|
Renamed |
2020 Vulin Republic of Panama, Panama City - Call sign: 3FCJ2 Reg. Owner: Vulin Inc. Manager: We Ships Denizcilik ve Ticaret A.Ş.- Turkey |
|
Latest data adjustment |
10 February 2021 |
