Bergen, Norway 29 May 2019 |
 |
| Bergen, Norway 29/05/19 |
|
Name |
ISLAND VANGUARD |
|
Type |
Offshore anchor handling tug - Supply ship Type UT 787 CD |
|
Typical work |
Deep water anchor handling with fully integrated work ROV support Heavy duty mooring and subsea installation work Pre-laying of chain and synthetic rope at deep water Trenching work Light construction work P&A work Survey work IMR work Supply duties A-frame work over moonpool |
|
IMO-number |
9356189 |
|
Call sign |
LNVU |
|
Flag |
Norway |
|
Port of registry |
Aalesund |
|
GT |
5.733 t |
|
DWT |
Summer: 4.163 t |
|
NT |
1.754 t |
|
Length |
86,30 m overall 75,00 m between perpendiculars |
|
Breadth |
22,04 m extreme |
|
Draught |
Max: 7,71 m |
|
Depth |
9,50 m |
|
Speed |
Max: 16,5 knots |
|
Built |
2007 |
|
Keel laid |
06/02/2006 |
|
Launch date |
17/09/2006 |
|
Date of completion |
05/03/2007 |
|
Builder casco |
Aker Tulcea SA |
|
Builder completion |
Aker Yards AS Langsten |
|
Yard number |
2009 |
|
Hull material |
Steel |
|
Main engine |
2x Bergen Rolls Royce B32:40V12 combustion engines each 6.000 kW / 8.976 bhp |
|
Reduction gear |
2x Rolls Royce 3000 AGS |
|
Propellers |
2x Rolls-Royce 111XF5/4E controllable pitch propeller |
|
Shaft generator |
2x 2.500 kW each |
|
Generators |
2x Caterpillar 3516B diesel engines coupled with 2x AVK generators total 2.028 kVA 1x Caterpillar 3508Bdiesel engines coupled with AVK generator 875 kVA |
|
Emergency generator |
1x Caterpillar 3406 diesel generatorset |
|
Bollard pull |
227 t |
|
Deck area |
740 m² |
|
Dry bulk |
120 m³ |
|
Moonpool |
7.000 x 7.000 mm |
|
A-frame |
200 t fitted above moonpool |
|
Tank capacities |
Fuel oil: 1.000 m³ Fresh water: 1.000 m³ Brine: 700 m³ Base oil: 260 m³ Ballast: 3.294,7 m³ |
|
Anchor equipment |
Length: 550,00 m Diameter: 52 mm |
|
Lifting equipment |
1x MacGregor crane - SWL 15,0 t |
|
Accommodation |
54 pesons |
|
Manager |
Island Offshore Management AS |
|
Registered owner |
Island Offshore XII Ship AS |
|
Latest data adjustment |
08 September 2019 |
