Westerschelde 11 December 2019 |
 |
| Antwerpen 11/09/18 |
|
Name |
COMPASS |
|
Previous names |
2006 Melvin - Euro number 02327250 2007 St Rita 2017 Compass |
|
Type |
Inland tanker |
|
ENI-number |
06004305 |
|
Previous ENI-number |
2327250 |
|
Call sign |
PE2565 |
|
Flag |
The Netherlands |
|
Port of registry |
Nigtevecht |
|
GT |
2.022 t |
|
Tonnage |
2.991 t |
|
Length |
110,00 m |
|
Breadth |
11,45 m |
|
Draught |
3,60 m |
|
Depth |
5,35 m |
|
Built |
2006 |
|
Date of completion |
29/05/2006 |
|
Builder casco |
Stocznia Wroclaw Poland |
|
Builder completion |
Asto BV Raamsdonksveer The Netherlands |
|
Yard number |
58 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Caterpillar 3512 (B) DI-TA electronic combustion engine 1.773 hp / 1.305 kW at 1.600 rpm Built: 2005 Builder: Caterpillar Tractor Corp., Lafayette, IN - USA |
|
Gearbox |
Reintjes type WAF 763 L - Reduction: 5,136:1 |
|
Propellers |
1x Screw propeller solid |
|
Generators |
1x Diesel generatorset 660 kVA - 528 kW 1x Diesel generatorset 78 kVA - 62 kW - 82 hp |
|
Bow thruster |
1x Verhaar Omega-Jet 31120-4k with vertical electro motor 375 kW at 1.780 rpm |
|
Cargo tank capacity |
3.800 m³ |
|
Pumps |
10x MDPD-80 deepwell pumps |
|
Owner |
Compass Tankvaart BV Dorpsstraat 16 1393 NH Nigtevecht The Netherlands |
|
Previous names & owner |
2006 Melvin - Arjan BV in Overslag - The Netherlands 2007 St Rita - Glamona in Zantvliet - The Netherlands 2017 Compass - Compass Tankvaart BV in Nigtevecht - The Netherlands |
|
Latest data adjustment |
27 May 2022 |
