Westerschelde 11 May 2019 |
 |
 |
 |
 |
|||
| Terneuzen 16/08/2019 | Terneuzen 16/08/2019 | Westerschelde 26/03/18 | Antwerpen 07/05/19 | |||
|
Name |
FALSTRIA SWAN |
|
Previous names |
2006 - 06/2012 Ingrid Jakobsen |
|
Type |
Chemical/Oil products tanker |
|
IMO-number |
9367217 |
|
Call sign |
V2XW |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John’s |
|
GT |
3.933 t |
|
DWT |
Summer: 6.883,5 t |
|
NT |
1.940 t |
|
Length |
103,00 m overall 96,74 m between perpendiculars |
|
Breadth |
16,00 m extreme |
|
Draft |
Summer: 7,00 m 3,11 m ballast |
|
Keel to mast end |
30,00 m |
|
Air draft |
26,00 m in ballast 23,00 m loaded condition |
|
Depth |
8,70 m |
|
Speed |
12,8 knots ballast 12,0 knots loaded |
|
Built |
2006 |
|
Keel laid |
28/12/2004 |
|
Launch date |
05/10/2005 |
|
Date of completion |
16/11/2006 |
|
Builder |
Nanjing Shenghua Shipbulding Co., Ltd. Nanjing China |
|
Yard number |
405 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
11 |
|
Continuous decks |
1 |
|
Main engine |
1x Caterpillar MaK 8M25 - 4 stroke 8 cylinder 255 x 400 mm combustion engine 2.400 kW / 3.261 hp at 750 rpm Manufacturer: Caterpillar GmbH & Co. KG |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired LSH5-0.7 1x Auxiliary boiler, composite LYF0.8/0.6-0.7 |
|
Shaft generator |
600 kW |
|
Generators |
2x Cummins KTA 19 D(M) main diesel generatorsets each 525 kVA - 420 kW - 571 hp |
|
Emergency generator |
1x Cummins diesel generatorset 200 kVA - 160 kW - 217 hp |
|
Bow thruster |
1x 300 kW, forward |
|
Number of cargo tanks |
12 + 2 slop tanks |
|
Cargo tank capacity 98% |
6.654,67 m³ |
|
Number of segregations |
3 |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
111,57 m³ |
|
Pumps |
5x Cargo pumps each 500 m³/h 2x Ballast pumps each 200 m³/h |
|
Manifolds |
Distance from bow to centre manifold: 53,60 m Distance from stern to centre manifold: 49,40 m Distance between manifolds: 1,115 m Distance from ship side to manifold: 2,30 m Distance from deck / tray to manifold: 2,30 m / 1,55 m |
|
Tank capacities |
Ballast: 2.556,4 m³ |
|
Anchor equipment |
Length: 550,00 m Diameter: 42 mm |
|
Lifting equipment |
1x Provision/hose crane - SWL 1,0 t |
|
ISM & commercial manager |
Uni-Tankers A/S Turbinevej 10 5500 Middelfart Denmark |
|
Previous managers |
2006 - 06/2012 Ibex Maritime Ltd. - Istanbul - Turkey |
|
Owner |
Uni-Tankers m/t "Falstria Swan" ApS |
|
Registered owner |
M/T Falstria Swan ApS Care of Uni-Tankers A/S Turbinevej 10 5500 Middelfart Denmark |
|
Previous owners |
2006 - 06/2012 Ingrid Jakobsen K/S - Istanbul - Turkey |
|
Latest data adjustment |
16 November 2021 |
