Tenacity - IMO 9416408

Antwerpen 30 January 2018

Name

TENACITY

Type

Tanker for chemicals & Oil products

Main products

Clean petroleum products - Vegetable oils/Palm oils - Easy chemicals

IMO-number

9416408

Call sign

D5DN7

Flag

Liberia

Port of registry

Monrovia

GT

29.715 t

DWT

Summer: 50.413 t

NT

14.589 t

Displacement

62.174,43 t

Length

183,20 m overall

178,50 m between perpendiculars

Breadth

32,26 m moulded

Draught

12,91 m

Distance keel to top of mast

44,50 m

Depth

18,20 m moulded

Speed

14,5 knots laden

Built

2014

Keel laid

29/03/2013

Launch date

12/01/2014

Date of completion

07/07/2014

Builder

Guangzhou Shipyard International Co. Ltd.
Guangzhou
China

Yard number

06130023

Hull material

Steel

Hull type

Double bottom

Double side

Main engine

1x MAN 6S50ME-B9.2-TIER II - 6 cylinder combustion engine 10.680 KW

Propellers

1x Fixed pitch propeller

Boilers

1x Auxiliary boiler, composite MISSION OC

1x Auxiliary boiler, oil/gas fired MISSION OL
Manufacturer: Alfa Laval Aalborg

Generators

3x MAN 6L23/30H main diesel generatorsets each 960 kW

Emergency generator

1x 145 kW

Number of cargo tanks

12x Tanks including slops

Cargo tank capacity 98%

Segregation 1:
No.1 COT(P): 3.480,843 m³
No.1 COT(S): 3.507,878 m³

Segregation 2 :
No.2 COT(P): 4.901,837 m³
No.2 COT(S): 4.902,977 m³

Segregation 3:
No.3 COT(P): 4.336,112 m³
No.3 COT(S): 4.337,263 m³

Segregation 4:
No.4 COT(P): 4.336,112 m³
No.4 COT(S): 4.337,263 m³

Segregation 5:
No.5 COT(P): 4.336,113 m³
No.5 COT(S): 4.337,264 m³

Segregation 6:
No.6 COT(P): 4.328,789 m³
No.6 COT(S): 4.329,940 m³
Segregation 7 : Slop , P&S = 5.700,25 m³

Total: 51.475,391 m³ excl. slop tanks

Slop tank capacity 98%

5.700,252 m³

Pumps

10x Deepwell cargo pumps each 550 m³/h

2x Deepwell cargo pumps each 300 m³/h

1x Cargo pump 70 m³

Manifolds

Bow to centre manifolds: 92,00 m

Distance between cargo manifold centres: 2,00 m

Tank capacities

Ballast: 21.216,57 m³

Anchor equipment

Length: 632,50 m

Diameter: 73 mm

Lifting equipment

1x crane - SWL 10,0 t

Manager

Sea Pioneer Shipping Corporation
Leof. Kifisias 284
Athens 152 32
Greece

Technical & commercial operator

Sea Pioneer Shipping Corporation
284 Kifisias Avenue
152 32 Halandri
Athens
Greece

Registered owner

Tenacity Marine Inc.
80 Broad Street
Monrovia
Liberia

Latest data adjustment

07 March 2018
