Vlissingen, The Netherlands 12 July 2018 |
|
Name |
TEAM VOYAGER |
|
Previous names |
05/2016 - 04/2018 Siteam Voyager |
|
Type |
Tanker for oil product and chemicals |
|
IMO-number |
9326926 |
|
Call sign |
ZCEP5 |
|
Flag |
Bermuda |
|
Port of registry |
Hamilton |
|
Previous flags |
Republic of Singapore, Singapore city - Call sign: 9VVN3 |
|
GT |
26.809 t registered |
|
DWT |
45.916,1 t |
|
NT |
14.147 t registered |
|
Length |
182,90 m overall 176,00 m between perpendiculars |
|
Breadth |
32,20 m moulded |
|
Draught |
Max: 12,22 m |
|
Freeboard |
5.034 mm |
|
Speed |
Max: 15,3 knots |
|
Built |
2008 |
|
Keel laid |
31/05/2007 |
|
Date of completion |
29/04/2008 |
|
Builder |
Trogir Shipyard (Brodotrogir d.d.) |
|
Yard number |
317 |
|
Hull material |
Forged steel High strength steel |
|
Hull type |
Double hull |
|
Watertight bulkheads |
14 |
|
Main engine |
1x MAN-B&W 6S50MC-C - 6 cylinder 500 x 1.910 mm combustion engine 8.200 kW at 121 rpm Manufacturer: Uljanik Strojogradnja dd |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
2x Auxiliary oil fired boiler Mission OM 14t/h - 12,0 bar 1x Unfired exhaust gas boiler AQ-7 - 12,0 bar |
|
Generators |
3x Main diesel generatorset each 1.389 kW |
|
Number of cargo tanks |
22 |
|
Cargo tank capacity 100% |
83.534,2 m³ |
|
Number of slop tanks |
1 |
|
Number of tanks |
Ballast: 17 Fuel oil: 11 Lubricating oil: 6 Fresh water: 4 Diesel oil: 3 Chain: 2 Hydraulic oil: 2 Sewage: 1 |
|
Tank capacities 100% |
Diesel oil: 104,1 m³ Freshwater: 859.3 m³ Fuel oil: 2.160,6 m³ Hydraulic oil: 23,4 m³ Lube oil: 112,5 m³ Tank Ballast: 19.472,6 m³ |
|
Lifting equipment |
1x Hose handling crane - SWL 15,0 t 1x Provision crane - SWL 2,0 t 1x Rescue boat crane - SWL 2,0 t |
|
Commerical manager |
Team Tankers International |
|
Technical manager |
Team Tankers Maritime |
|
Operator |
Selandia Ship Management India |
|
Registered owner |
Team Tankers Deep Sea Ltd. |
|
Latest data adjustment |
20 July 2019 |
