Westerschelde 04 April 2019 |
 |
 |
|
| Westerschelde 07/08/16 | Westerschelde 07/08/16 | |
|
Name |
KEY WEST |
|
Previous names |
1992 - 1997 Roland Essberger 1997 - 08/2008 Douro Chemist 08/2008 - 04/2015 Roland Essberger |
|
Type |
Chemical tanker |
|
IMO-number |
9020429 |
|
Call sign |
ZDPE7 |
|
Flag |
Gibraltar |
|
Port of registry |
Gibraltar |
|
Previous flags |
Portugal, Madeira - Call sign: CQZU |
|
GT |
2.634 t |
|
DWT |
Summer: 3.741 t |
|
NT |
1.101 t |
|
Length |
89,99 m overall 85,53 m registered |
|
Breadth |
14,40 m registered |
|
Draught |
6,14 m |
|
Forecastle |
12,08 m |
|
Poop |
22,70 m |
|
Speed |
14,2 knots |
|
Built |
1992 |
|
Keel laid |
25/05/1992 |
|
Launch date |
03/07/1992 |
|
Date of completion |
05/10/1992 |
|
Builder |
J.J. Sietas KG Schiffswerft GmbH & Co. Neuenfelder Fährdeich 88 21129 Hamburg Federal Republic of Germany |
|
Yard number |
1074 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Single hull partly double bottom (e.g. interrupted in way of machinery space) |
|
Watertight bulkheads |
10 |
|
Continuous decks |
1 |
|
Main engine |
1x Krupp MaK 6M453C - 4 stroke 6 cylinder 320 x 420 mm combustion engine 1.980 kW/ 2.692 hp at 600 rpm Year of manufacture: 1992 Manufacturer: Caterpillar Motoren GmbH & Co. KG Falckensteiner Str. 2 24159 Kiel Federal Republic of Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 132 rpm |
|
Boilers |
1x Steam boiler, oil fired - 10,0 bar Heating surface: 52,0 m² 1x Steam boiler, exhaust gas heated - 10,0 bar Heating surface: 140,5 m² Year of manufacture: 1992 Manufacturer: Alfa Laval Aalborg A/S Gasvaerksvej 24 9100 Aalborg Kingdom of Denmark |
|
Electric installations |
1x Plant 450/220 V - 260 kVA 1x Plant 450/220 V - 310 kVA 1x Plant 450 V - 900 kVA 1x Plant 450 V - 60 kVA |
|
Shaft generator |
1x 900 kVA |
|
Generators |
1x Main diesel generatorset 310 kVA 1x Main diesel generatorset 260 kVA |
|
Emergency generator |
1x Diesel generatorset 60 kVA |
|
Compressed air receivers |
2x Receivers each 250 litres - 30,0 bar 1x Receiver 1.000 litres - 11,0 bar |
|
Bow thruster |
1x Fixed pitch propeller PLEUGER - 238 kW, forward |
|
Number of tanks |
18 |
|
Total tank capacity 98% |
3.933,2 m³ |
|
Number of slop tanks |
1 |
|
Slop tank capacity 98% |
75,5 m³ |
|
Number of pumps |
10x Cargo pumps each 150 m³/h 8x Cargo pumps each 100 m³/h 1x Cargo pumps each 120 m³/h |
|
Tank capacities |
Fuel oil: 200 m³ Water ballast: 1.560 m³ |
|
Anchor equipment |
3x Anchors weight each 2.100 kg Chain length: 440,00 m Diameter: 36 mm |
|
Lifting capacity |
1x Crane - SWL 1,0 t 1x Crane - SWL 3,7 t |
|
Crew size |
13 |
|
Manager |
Sea Tank Chartering AS Skuteviksbodene 22 5035Bergen Norway |
|
ISM Manager |
Fjord Shipping AS Gate 1, nr. 80 6700 Måløy Norway |
|
Registered owner |
Key Shipping AS Care of Sea Tank Chartering AS Skuteviksbodene 22 5035 Bergen Norway |
|
Previous names & owners |
1992 - 1997 Roland Essberger - BTR Biscaya Tank-Reederei GmbH, Mandeira - Portugal 1997 - 08/2008 Douro Chemist - Transocean Shipmanagement - Germany 08/2008 - 04/2015 Roland Essberger - BTR Biscaya Tank-Reederei GmbH & Co. KG , Hamburg - Germany |
|
Latest data adjustment |
02 July 2021 |
