Westerschelde 8 January 2019 |
 |
 |
 |
 |
 |
||||
| Westerschelde 10/11/15 | Westerschelde 18/12/17 | Westerschelde 12/04/19 | Westerschelde 12/04/19 | Westerschelde 12/04/19 | ||||
|
Name |
GRAN COUVA |
|
Type |
Tanker for oil & chemicals |
|
IMO-number |
9380520 |
|
Call sign |
VREK4 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Kong |
|
GT |
29.266 t |
|
DWT |
Summer: 47.128 t |
|
NT |
12.026 t |
|
Length |
183,21 m overall |
|
Breadth |
32,20 m |
|
Draught |
12,21 m |
|
Reg. dimensions L x B x D |
175,56 x 32,20 x 18,80 m |
|
Rule dimensions L x B x D |
174,00 x 32,20 x 18,80 m |
|
Keel to mast end |
47,48 m |
|
Freeboard |
6.613 mm |
|
Depth |
18,80 m |
|
Speed |
15,4 knots |
|
Built |
2008 |
|
Keel laid |
16/06/2008 |
|
Launch date |
25/08/2008 |
|
Date of completion |
20/10/2008 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. Ulsan South Korea |
|
Yard number |
2027 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Number of decks |
1 |
|
Watertight bulkheads |
Transverse: 10 |
|
Continuous decks |
1 |
|
Main engine |
1x HHI/MAN-B&W 6S50MC-C - 2 stroke single acting 6 cylinder 500 x 2.000 mm combustion engine Mcr 9.480 kW / 12.889 bhp at 127,0 rpm Built: 06/2008 Manufacturer: Hyundai Heavy Ind. Engine & Machinery, Ulsan - South Korea |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
Auxiliary Boiler WTB - 8,8 kg/cm² Heating surface: 191,8 m² Economizer WTB - 11,7 kg/cm² Heating surface: 366,0 m³ Built: 04/2008 Manufacturer: Kangrim Heavy Industrial Co., Ltd., Changwon - South Korea |
|
Generators |
3x Main diesel generatorsets each 912 kVA - 450 Volt |
|
Number of tanks |
12 + 2 slop tanks |
|
Tank capacity |
Seg#1: 6.763,8 m³ (1p/s) Seg#2: 9.138,8 m³ (2p/s) Seg#3: 9.317,6 m³ (3p/s) Seg#4: 9.317,6 m³ (4p/s) Seg#5: 9.300,8 m³ (5p/s) Seg#6: 8.068,2 m³ (6p/s) Seg#7: 1.174,8 m³ (slop p/s) |
|
Number of pumps |
12x Framo cargo pumps each 600 m³ 2x Framo cargo pumps each 300 m³ 2x Ballast pumps each 900 m³/h |
|
Max loading rate |
3.600 m³/h |
|
Max discharging rate |
3.600 m³/h |
|
Tank capacities |
Fuel oil: 1.422,2 m³ Fresh water: 292,8 m³ Water ballast: 4.690,9 m³ |
|
Lifting equipment |
1x Hose handling crane - SWL 10,0 t x 24,00 m 1x Engine room crane - SWL 2,0 t x 5,10 m 1x Provision crane - SWL 2,0 t x 9,50 m |
|
Manager |
Cido Shipping (Hong Kong) Co., Ltd. 20th Floor, World Wide House, 19, Des Voeux Road Central Hong Kong China |
|
ISM manager |
Executive Ship Management Pte. Ltd. 21-00/22-00, 78, Shenton Way Singapore 079120 Republic of Singapore |
|
Registered owner |
Heroic Grus Inc. Care of Cido Shipping (HK) Co Ltd. 20th Floor, World Wide House, 19, Des Voeux Road Central Hong Kong China |
|
Latest data adjustment |
14 August 2022 |
