Westerschelde 16 November 2015 |
 |
 |
 |
 |
 |
||||
| Westerschelde16/11/15 | Antwerpen 01/09/16 | Antwerpen 01/06/16 | Westerschelde 02/05/50 | Westerschelde 13/05/20 | ||||
|
Name |
CHEM ROTTERDAM |
|
Type |
Tanker for oil and chemicals |
|
IMO-number |
9640140 |
|
Call sign |
V7EJ3 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
GT |
11.733 t registered |
|
DWT |
Summer: 19.803,71 t |
|
NT |
6.115 t registered |
|
Length |
141,00 m overall |
|
Breadth |
24,20 m moulded |
|
Draught |
Summer: 9,71 m |
|
Moulded L x B x D |
133,00 x 24,20 x 13,20 m |
|
Registered L x B x D |
133,21 x 24,20 x 13,20 m |
|
Keel to mast end |
36,37 m |
|
Freeboard |
3.515 mm |
|
Depth |
13,20 m moulded |
|
Speed |
Max.: 16,8 knots Service: 14,5 knots |
|
Built |
2014 |
|
Keel laid |
26/06/2013 |
|
Launch date |
19/12/2013 |
|
Date of completion |
25/03/2014 |
|
Builder |
Kitanihon Shipbuilding Co., Ltd. Hachinohe Japan |
|
Yard number |
573 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Mitsubishi-Akasaka 6UEC43LSI - 2 stroke single acting 6 cylinder 430 x 1.500 mm combustion engine 6.230 kW / 8.470 hp at 160,0 rpm Manufacturer: Akasaka Diesels Ltd., Shizuoka - Japan |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 410 mm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary vertical boiler - 9,0 bar Evaporation: 16,23 t/h Manufacturer: Miura Co., Ltd. |
|
Generators |
4x Generatorsets total 2.164 kVA |
|
Bow thruster |
1x 685 kW |
|
Number of tanks |
14 + 2 slop tanks |
|
Number of slop tanks |
2 |
|
Segregations |
16 |
|
Cargo tank capacity |
Liquid: 22.125 m³ |
|
Number of pumps |
14x Cargo pumps each 250 m³/h |
|
Tank capacities |
Fuel oil: 1.039 m² Fresh water: 412 m³ Water ballast: 7.147 m³ |
|
Manager |
Ace Tankers CV Strawinskylaan 1057, Tower D, Level 10 1077 XX Amsterdam The Netherlands |
|
ISM manager |
ASM Maritime B.V. 10, Tower D, WTC, Strawinskylaan 1057 1077 XX Amsterdam The Netherlands |
|
Registered owner |
Chem Rotterdam SA Majuro Marshall Islands |
|
Latest data adjustment |
26 July 2022 |
