Name |
GOLFSTRAUM |
|
Type |
Tanker for oil and chemicals |
|
IMO-number |
9390991 |
|
Call sign |
LAJK6 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
GT |
7.243 t |
|
DWT |
Summer: 9.595 t |
|
NT |
3.078 t |
|
Length |
129,00 m overall 120,04 m between perpendiculars |
|
Breadth |
19,20 m extreme |
|
Draught |
7,74 m |
|
Freeboard |
2.074 mm |
|
Depth |
9,80 m |
|
Speed |
14,0 knots |
|
Built |
2011 |
|
Keel laid |
14/05/2007 |
|
Launch date |
04/06/2008 |
|
Date of completion |
17/11/2011 |
|
Builder casco |
3. Maj Brodogradiliste d.d. Rijeka Croatia Yard number: 714 |
|
Builder outfitting |
Cantiere Navale De Poli Venezia Italy Yard number: 242 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Number of decks |
1 |
|
Main engine |
1x MAN-B&W 9L32/40 - 9 cylinder cobustion engine 4.500 kW at 750 rpm |
|
Propellers |
1x Controllable pitch propeller Builder: Scana Volda AS |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated GMT-EC-M 1700 - 12,0 bar 2x Auxiliary boiler, oil/gas fired NG-VM 3500 - 10,0 bar Builder: Garioni Naval Castelmella, Brescia - Italy |
|
Generators |
3x Mitsubishi D34A-MS diesel generatorsets Builder: Mitsubishi Heavy Industries Ltd., Sagamihara Machinery Works |
|
Emergency generator |
1x Volvo Penta D9 diesel generatorset |
|
Bow thruster |
1x 524 kW |
|
Number of tanks |
16 |
|
Cargo tank capacity 98% |
10.606 m³ |
|
Number of slop tanks |
2 |
|
Number of pumps |
16 cargo pumps each 300 m³/h |
|
Tank capacities |
Ballast: 4.146,7 m³ |
|
Anchor equipment |
Length: 522,50 m Diameter: 50 mm |
|
Manager |
Utkilen AS Strandgaten 197 5004 Bergen Norway |
|
Registered owner |
Utkilen Chemtrans AS Strandgaten 197 5004 Bergen Norway |
|
Latest data adjustment |
07 June 2021 |
