| Antwerpen 22 May 2013 |
 |
 |
 |
||
| Antwerpen 22/05/13 | Antwerpen 30/05/14 | Antwerpen 14/07/19 | ||
|
Name |
JASMAR |
|
Type |
Inland vessel |
|
ENI-number |
04808580 |
|
Call sign |
DG2190 |
|
Flag |
Germany |
|
Port of registry |
Dessau |
|
Tonnage |
2.282 t |
|
Length |
104,90 m |
|
Breadth |
10,04 m |
|
Draught |
3,40 m |
|
Depth |
5,40 m |
|
Built |
2011 |
|
Builder |
Groningen Shipyard Waterhuizen The Netherlands |
|
Hull material |
Steel |
|
Main engine |
1x Mitsubishi S 12 R-C2MPTK - 1.278 hp / 940 kW at 1.600 rpm |
|
Propellers |
1x 5-Blades Promarin propeller diameter 1.700 mm with nozzle Van de Giessen Optima diameter 1.714 mm |
|
Generators |
1x Cummins QSX 15C diesel engine coupled with Marathon 572 PSL 4028 generator 450 kVA 1x John Deere 6068 HFU72 diesel engine coupled with Marathon 431 PSL 6202 generator 127 kVA 1x John Deere 4045 TFU70 diesel engine coupled with Marathon 362 CSL 1604 generator 63 kVA |
|
Bow thruster |
1x Cummins - Verhaar Omega-Jet type 03100-4k- 383 hp / 282 kW at 1.780 rpm |
|
Cargo pumps |
2x Bornemann type EPS500 - 500 m³/h powered by an electro engine 132 kW each |
|
Lifting equipment |
1x Car crane - SWL 2.500 kg |
|
Operator |
Bout Tankschiffahrt KG Markheidenfeld Germany |
|
Owner |
Brant Bout |
|
Latest data adjustment |
16 January 2015 |
