Westerschelde 27 August 2018 |
 |
 |
 |
 |
 |
||||
| Westerschelde 27/08/18 | Vlissingen 10/11/12 | Vlissingen 10/11/12 | Vlissingen 10/11/12 | Westerschelde 16/04/16 | ||||
|
Name |
LONDON STAR |
|
Type |
Crude oil tanker |
|
IMO-number |
9330343 |
|
Call sign |
A8KN4 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
41.966 t |
|
DWT |
73.869 t |
|
NT |
44.780 t Panama: 34.669 t |
|
Length |
228,60 m overall 218,00 m between perpendiculars |
|
Breadth |
32,30 m extreme 32,26 m moulded |
|
Draught |
14,46 m |
|
Keel to masthead |
48,92 m |
|
Freeboard |
Summer: 6.365 mm Winter: 6.466 mm Tropical: 5.864 mm |
|
Depth |
20,80 m moulded |
|
Built |
2006 |
|
Keel laid |
03/12/2004 |
|
Date of completion |
27/10/2006 |
|
Builder |
New Century Shipbuilding Co., Ltd. Jingjiang China |
|
Yard number |
0307319 |
|
Hull material |
Steel - Part higher tensile steel |
|
Hull type |
Double Hull |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 5S60MC-C - 2 stroke 5 cylinder 600 x 2.400 mm combustion engine 11.290 kW / 15.350 hp at 105,0 rpm |
|
Propellers |
1x Fixed pitch propeller |
|
Number of tanks |
120+ 2 slop tanks |
|
Tank capacity 98% |
Each natural segregation with double valve (specify tanks): Seg#1: 28.335,44 m³ (1P, 1S, 4P, 4S, SLOP-P, SLOP-S) Seg#2: 28.491,10 m³ (2P, 2S, 5P, 5S) Seg#3: 26.467,72 m³ (3P, 3S, 6P, 6S) |
|
Total cubic capacity 98% |
80.472,71 m³ excluding slop tanks |
|
Slop tanks capacity 98% |
3.140,52 m³ |
|
Maximum loading rate |
For homogeneous cargo per manifold connection: 2.667 m³/h For homogeneous cargo loaded simultaneously through all manifolds: 8.000 m³/h |
|
Number of pumps |
6x Centrifugal cargo pumps each 2.300 m³/h 3x Stripping screw pumps each 250 m²/h 2x Centrifugal ballast pumps each 1.500 m³/h |
|
Manifolds |
Bow to centre manifold: 114,75 m Stern to centre manifold: 113,85 m Distance bridge front to centre of manifold: 64,00 m Distance ships rail to manifold: 4.440 mm Distance between cargo manifold centres: 2.500 mm Distance manifold to ships side: 4.600 mm Top of rail to centre of manifold: 762 mm Distance main deck to centre of manifold: 2.100 mm |
|
Tank capacities |
Fuel oil: 2.194,77 m³ Diesel oil: 384,89 m³ |
|
Lifting equipment |
1x Crane - SWL 15,0 t - midship |
|
Commercial manager |
Chemikalien Seetransport GmbH Mattentwiete 1 D-20457 Hamburg Germany |
|
Operator |
Penfield Tankers 200 Pequot Avenue Southport,CT 06890 USA |
|
Registered owner |
Partankers XXIV AS Hamburg Germany |
|
Latest data adjustment |
11 January 2024 |
