| Westerschelde 04 December 2012 |
|
Name |
SOUTHERN ATLAS |
|
Type |
Oil / Chemical carrier |
|
IMO-number |
9355393 |
|
Call sign |
3EEG9 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
5.551 t |
|
DWT |
8.905,28 t |
|
NT |
2.785 t |
|
Length |
115,50 m overall |
|
Breadth |
18,73 m |
|
Draught |
7,61 m |
|
Moulded L x B x D |
108,50 x 18,70 x 10,00 m |
|
Registered L x B x D |
108,79 x 18,70 x 10,00 m |
|
Freeboard |
Summer: 2.412 mm |
|
Depth |
10,00 m moulded |
|
Speed |
13,5 knots |
|
Built |
2006 |
|
Keel laid |
27.12.2004 |
|
Launch date |
21.12.2005 |
|
Date of completion |
04.04.2006 |
|
Builder |
Shitanoe Shipbuilding Co., Ltd. |
|
Yard number |
1251 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN B&W 6L35MC-MK6 - 2 stroke single acting 6 cylinder 350 x 1.050 mm diesel engine - 3.900 kW / 5.310 hp at 210,0 rpm Manufacturer: Imex Co., Ltd. |
|
Propellers |
1 |
|
Propeller shaft |
1x Sea water lubrication shaft |
|
Boilers |
1x Auxiliary vertical boiler - 9,8 bar Evaporation: 10,0 t/h Manufacturer: Miura Protec Co., Ltd. |
|
Generators |
4x Diesel generatorsets - 1.540 kVA |
|
Liquid tank capacity |
9.883 m³ |
|
Tank capacities |
Fuel oil: 626 m³ Fresh water: 257 m³ Water ballast: 2.863 m³ |
|
Manager |
Tatsumi Marine Services Pte., Ltd. |
|
Operator |
Southern Shipping Pte., Ltd. |
|
Owner |
Sansho Kaiun |
|
Registered owner |
Sansho Line, S.A. |
|
Last update |
24.02.2013 |
