Westerschelde 22 July 2019 |
|
Name |
LYRIC CAMELLIA |
|
Type |
Crude oil tanker - Aframax |
|
IMO-number |
9730933 |
|
Call sign |
C6BT5 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
GT |
63.694 t registered Suez: 65.733 t |
|
DWT |
Summer: 109.999 t |
|
NT |
32.856 t registered Suez: 59.173 t |
|
Lightship |
20.291,9 t |
|
Length |
249,90 m overall 239,00 m between perpendiculars |
|
Breadth |
44,00 m moulded |
|
Draught |
Summer: 14,64 m Ballast: 7,28 m |
|
Keel to masthead |
51,63 m |
|
Depth |
21,50 m moulded |
|
Speed |
Max: 16,0 knots |
|
Built |
2016 |
|
Keel laid |
23/07/2015 |
|
Delivery date |
29/02/2016 |
|
Builder |
Sungdong Shipbuilding and Marine Engineering Co., Ltd. Tongyeong South Korea |
|
Yard number |
S3105 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x Hyundai/MAN-B&W 6G60ME-C9 - 2 stroke single acting 600 x 2.790 mm combustion engine 11.350 kW / 15.431 hp at 80,0 rpm Builder: Hyundai Heavy Industries Co., Ltd. - South Korea |
|
Propellers |
1x Fixed pitch propeller - aft at 80,0 rpm |
|
Boilers |
2x Auxiliary boiler 1x Composite boiler Builder: Aalborg |
|
Generators |
3x Hyundai Himsen 6H21/32 - 4 stroke 6 cylinder 210 x 320 mm diesel engines each 1.200 kW at 900 rpm connected with generators each 1.140 ekW - 450 Volt 60 Hz Builder: Hyundai Himsen |
|
Emergency generator |
1x Doosan AD158TIS diesel engine 280 kW at 1.800 rpm |
|
Number of tank |
12 |
|
Cargo tank capacity 98% |
No 1 COT (P) 7.809,60 m³ No 1 COT (S) 7.795,20 m³ No 2 COT (P) 11.170,10 m³ No 2 COT (S) 11.170,30 m³ No 3 COT (P) 11.325,70 m³ No 3 COT (S) 11.331,70 m³ No 4 COT (P) 11.305,90 m³ No 4 COT (S) 11.333,70 m³ No 5 COT (P) 11.310,90 m³ No 5 COT (S) 11.332,30 m³ No 6 COT (P) 10.062,10 m³ No 6 COT (S) 10.063,00 m³ SLOP T(P) 755,70 m³ SLOP T(S) 1.173,90 m³ Total: 127.940,1 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
1.940 m³ |
|
Residual oil tank 98% |
416 m³ |
|
Pumps |
3x Vertical centrifugal single stage driven by stream turbine in engine room cargo pumps each 3.000 m³/h 2x Vertical centrifugal single stage driven by stream turbine in engine room each 1.500 m³/h |
|
Manifolds |
Manifold centre to ship side: 7,60 m Manifold centre to main deck level: 2,10 m Manifold centre to keel level: 23,60 m |
|
Tank capacities |
HFO: 2.73,5 t MGO: 732,2 t Water ballast: 41.733,8 m³ |
|
Crew size |
23 |
|
Manager |
Orpheus Marine Transport Corp. Paradisou 2 Marousi 151 25 Greece |
|
Operator |
V Ships UK Ltd. |
|
Registered owner |
Evergreen Shipping Holdings Care of Lyras Maritime Ltd. 24-26, Baltic Street, Barbican London, EC1Y 0RP United Kingdom |
|
Latest data adjustment |
11 October 2020 |
