Westerschelde 05 April 2015 |
|
Name |
BBS SKY |
|
Previous names |
2000 - 12.2012 Arklow Sky |
|
Type |
Multi-purpose cargo ship - Heavycargo - Strengthbottom |
|
IMO-number |
9196266 |
|
Call sign |
C6AM4 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
Previous flags |
04.200 - 12.2007 The Netherlands, Zaandam - Call sign: PEBU 12.2007 - 12.2012 The Netherlands, Rotterdam - Call sign: PEBU |
|
GT |
2.316 t registered |
|
DWT |
Summer: 3.171 t |
|
NT |
1.295 t |
|
Number of 20ft containers |
In hold 76 On deck: 40 Total: 116 |
|
Length |
89,99 m overall 84,99 m between perpendiculars |
|
Breadth |
12,50 m extreme |
|
Draught |
Max.: 4,64 m 3,65 m ballast |
|
Air draft |
24,20 m ballast 19,80 m laden |
|
Freeboard |
1.180 mm |
|
Depth |
6,00 m moulded |
|
Speed |
11,0 knots |
|
Built |
2000 |
|
Launch date |
31.03.2000 |
|
Date of completion |
20.04.2000 |
|
Builder |
Scheepswerf & Machinefabriek Barkmeijer Stroobos B.V. Stroobos |
|
Yard number |
291 |
|
Hull material |
Steel |
|
Watertight bulkheads |
4 |
|
Movable bulkheads |
2 - 6 positions |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M20 - 4 stroke single acting 8 cylinder 200 x 300 mm diesel engine 1.360 kW / 1.847 hp at 1.000 rpm Starter type: Compressed air Built: 1999 Builder: MaK Motoren GmbH & Co. KG, Kiel - Germany |
|
Propellers |
1x Screw propeller solid - aft at 256 rpm Diameter: 2.350 mm - 5 blades |
|
Electric installations |
Power voltage: 400 V Lighting voltage: 230 V Frequency: 50 Hz |
|
Generators |
2x Valmet 620DSG - 6 cylinder 108 x 120 mm diesel engine at 1.500 rpm coupled with Stamford UCM274 E23 generator 120 kVA - 96 kW - 150 hp |
|
Emergency generator |
1x Valmet 320DSG - 3 cylinder 108 x 120 mm diesel engine at 1.500 rpm coupled with Stamford UCM224 E 63 kVA - 50 kW - 72 hp |
|
Bow thruster |
1x VethJet VT150 - 200 kW |
|
Number of holds |
1 62,00 x 10,20 x 7,45 m |
|
Total capacity of holds |
4.723 m³ / 166.890 ft³ |
|
Number of hatches |
1 - 9 pontoons |
|
Max. permitted loads |
Tanktop: 14,0 t/m² Hatches: 1,60 t/m² |
|
Tank capacities |
Capacity Of Tanks Ballastwater1.586 m³ Capacity Of Tanks Potable Water56.2 m³ Capacity Of Tanks Fuel92.5 m³ Capacity Of Tanks Lubricating Oil3.56 m³ |
|
Lifting equipment |
1x Gantry crane |
|
Previous managers |
04.2000 - 12.2012 Arklow Shipping Nederland B.V., Rotterdam - The Netherlands |
|
Registered owner |
BBS Bulk III KS |
|
Group |
Høyergruppen AS |
|
Previous names & owners |
04.2000 - 12.2007 Arklow Sky - Scheepvaartmaatschappij Titania, Heerenveen - The Netherlands 12.2007 - 12.2012 Arklow Sky - BBS Bulk III KS, Bergen - Norway |
|
Latest data adjustment |
04 December 2016 |
