Westerschelde 17 April 2014 |
 |
 |
|
| Westerschelde 17/04/14 | Antwerpen 06/05/20 |
|
Name |
WILSON CORINTH |
|
Previous names |
2005 - 2005 Hermann Wessels 2005 - 2014 Anna-Maria Sibum 2014 - 2014 Wilson Corinth 2014 - 2014 Anna-Maria Sibum |
|
Type |
Multi-purpose dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo |
|
IMO-number |
9158109 |
|
Call sign |
V2BB2 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
GT |
2.996 t |
|
DWT |
Summer: 4.435 t Winter: 4.297 t |
|
NT |
1.733 t |
|
Number of 20ft containers |
In hold: 129 On deck: 168 Total: 297 |
|
Container capacity 14t |
185 |
|
Reefer points |
30 on deck |
|
Length |
99,82 m overall 95,52 m between perpendiculars |
|
Breadth |
13,04 m extreme 12,80 m moulded |
|
Draught |
Summer: 5,68 m Winter: 5,56 m |
|
Keel to top antenna fwd / aft |
23,50 / 28,80 m |
|
Air draft |
Max: 25,0 m |
|
Depth |
7,55 m to main deck |
|
Speed |
Service: 10,0 knots |
|
Built |
2005 |
|
Keel laid |
25/03/1998 |
|
Launch date |
09/01/2005 |
|
Date of completion |
14/07/2005 |
|
Builder |
AD Brodogradiliste 'Sava' D.D. Macvanska Mitrovica Serbia |
|
Yard number |
3014 |
|
Hull material |
Steel |
|
Movable bulkheads |
2 8 positions, 2 storage positions |
|
Number of decks |
1 |
|
Main engine |
1x MWM TBD645L6 - 6 cylinder combustion engine 3.467 bhp / 2.550 kW |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired |
|
Shaft generator |
1x 675 kW |
|
Generators |
2x Deutz-MWM TBD234V8 diesel generatorsets each 190 kW |
|
Emergency generator |
1x Deutz F6L912 diesel generatorset |
|
Bow thruster |
220 kW |
|
Number of holds |
1x Box 70,85 x 10,20 x 8,17 m |
|
Hold capacity |
Bale: 5.764 m³ - 203.563 ft³ Grain: 5.841 m³ - 206.273 ft³ |
|
Hold ventilation |
6 times/h |
|
Number of hatches |
2 Hatch 1: 37,95 x 10,2 m Hatch 2: 31,20 x 10,2 m |
|
Hatch type |
Kvaerner multifold, Crocodile |
|
Max permitted loads |
Deck/hatch-cover: 1,7 t/m² Tanktop: 15,0 t/m² |
|
Tank capacities |
Ballast: 1.570,6 m³ Fresh water: 52 t MGO: 271 m³ Gas oil: 36 t |
|
Anchor equipment |
Length: 567,50 m Diameter: 36 mm |
|
Manager |
Reederei Bernd Sibum GmbH & Co. KG Gartenstraße 37 49733 Haren (Ems) Germany |
|
Owner |
AMASI Schifffahrts GmbH & Co. KG Emsstr. 44 49733, Haren (Ems) Germany |
|
Operator |
Wilson ASA Bradbenken 1 Sandviken N-5835 Bergen Norway |
|
Previous owners |
2005 - 2005 Wesco Sh GmbH & Co. KG 2005 - 2005 MS "Anna-Maria Sibum" Schiffahrts GmbH & Co. KG 2005 - 2006 Reederei Bernd Sibum GmbH & Co. KG 2006 - 2014 MS "Anna-Maria Sibum" Schiffahrts GmbH & Co. KG |
|
Latest data adjustment |
30 July 2020 |
