Westerschelde 29 April 2016 |
 |
| Antwerpen 13/01/16 |
|
Name |
RAN J |
|
Previous names |
2011 - 04.2015 Industrial Force |
|
Type |
Multi-purpose dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo |
|
IMO-number |
9506746 |
|
Call sign |
V2FO5 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
GT |
12.810 t |
|
DWT |
Summer: 14.359,8 t Winter: 13.730 t |
|
NT |
5.938 t |
|
Number of 20ft containers |
985 |
|
Reefer plugs |
30 |
|
Length |
153,52 m overall 145,50 m between perpendiculars |
|
Breadth |
23,45 m extreme 23,21 m moulded |
|
Draught |
9,10 m |
|
Air draft |
35,00 m at ballast |
|
Depth |
12,80 m |
|
Speed |
16,5 knots |
|
Built |
2011 |
|
Keel laid |
04.12.2008 |
|
Launch date |
05.11.2010 |
|
Date of completion |
13.09.2011 |
|
Builder |
Sainty Shipbuilding (Yangzhou) Corp., Ltd. |
|
Yard number |
07STIG057 |
|
Hull material |
Steel |
|
Main engine |
1x Wärtsilä 6RT-Flex50-B - 6 cylinder diesel engine 9.960 kW |
|
Propellers |
1x Fixed propeller |
|
Boilers |
1x Thermal oil heater, exhaust heated type AWE 850 V 39 1x Thermal oil heater, oil fired type DWE 850 H 39 |
|
Generators |
3x Wärtsilä 6L20 main diesel generatorsets each 760 kW |
|
Emergency generator |
1x MAN D2876 LE 201 diesel generatorset |
|
Number of holds |
2 Hold 1: 12,75 x 13,20 x 7,95 m Hold 2 upper compartment: 83,75 x 19,00 x 6,10 m Hold 2 lower compartment: 77,25 x 19,00 x 5,45 m |
|
Hold capacity |
Grain/Bale: 19.800 m³ |
|
Deck space tween deck |
1.950 m² |
|
Max. permitted loads |
Tanktop: 20,0 t/m² Tween deck: 5,0 t/m² Weather deck: 5,0 t/m² |
|
Tank capacities |
Ballast: 6.546,8 m³ HFO: 1.360 m³ MDO: 290 m³ Fresh water: 90 m³ |
|
Anchor equipment |
Length: 577,50 m Diameter: 58 mm |
|
Cargo gear |
2x NMF cranes electric hydraulic cranes each 400 t 1x NMF cranes electric hydraulic cranes 80 t |
|
Manager |
Jüngerhans Heavy-Lift-Fleet Services GmbH & Co. KG |
|
Commercial managers |
Arkon Shipping GmbH & Co. KG Boschstrasse 16 D-49733 Haren (Ems) |
|
Registered owner |
MS "RAN J" Schiffahrtsgesellschaft mbH & Co. KG |
|
Latest data adjustment |
24 May 2016 |
