Westerschelde 12 November 2015 |
 |
| Westerschelde 12/11/15 |
|
Name |
MOLESON |
|
Type |
Bulk carrier |
|
IMO-number |
9542831 |
|
Call sign |
HBLE |
|
Flag |
Switzerland |
|
Port of registry |
Basel |
|
GT |
22.697 t Suez: 23.229,95 t |
|
DWT |
Summer: 34.266 t Winter: 33.279 t |
|
NT |
11.603 t Suez: 18.876,44 t |
|
Light ship |
8.530 t |
|
Length |
181,10 m overall 172,00 m between perpendiculars |
|
Breadth |
30,00 m extreme |
|
Draught |
9,82 m |
|
keel to mast end |
45,50 m |
|
Freeboard |
4.819 mm |
|
Depth |
14,60 m moulded |
|
Speed |
13,0 knots |
|
Built |
2010 |
|
Date of completion |
28.10.2010 |
|
Builder |
Shinan Heavy Industries Co., Ltd. |
|
Yard number |
H1006 |
|
Hull material |
Steel |
|
Main engine |
1x MAN-B&W-Doosan 6S50MC-C - 2 stroke 5 cylinder 500 x 2.000 mm diesel engine 8.580 kW / 11.658 hp at 127,0 rpm Built: 29.06.2010 Builder: Doosan Engine Co., Ltd., Changwon - South Korea |
|
Propellers |
1x Screw propeller solid - aft at 127 rpm |
|
Boilers |
1x CHM 223,50 m² - 8,0 bar |
|
Generators |
3x Main diesel generatorsets each 750 kVA - 600 kW - 883 hp |
|
Emergency generator |
1x Diesel generatorset 188 kVA - 150 kW - 190 hp |
|
Number of hold |
5 |
|
total capacity of holds |
Grain / Bale Hold 1: 8.245 m³ - 291.137 ft³ / 7.764 m³ - 274.412 ft³ Hold 2: 9.819 m³ - 347.143 ft³ / 9.265 m³ - 327.462 ft³ Hold 3: 9.835 m³ - 347.701 ft³ / 9.249 m³ - 326.897 ft³ Hold 4: 9.835 m³ - 347.701 ft³ / 9.267 m³ - 327.533 ft³ Hold 5: 9.355 m³ - 330.647 ft³ / 8.889 m³ - 314.173 ft³ |
|
Number of hatches |
5 Hatch 1: 16,80 x 15,00 m Hatches 2-5: 19,20 x 19,20 m |
|
Hatch type |
Folding type with hydraulic cylinders |
|
Max. permitted loads |
Tank top: 21 t/m² |
|
Tank capacities |
Fuel oil: 1.514,4 m³ |
|
Cargo gear |
4x Dongnam deck cranes - SWL 30 t each |
|
Crew |
21 |
|
Manager |
Suisse Atlantique Société de Navigation Maritime S.A. |
|
Registered owner |
Oceana Shipping AG c/o Suisse-Atlantique, Société de Navigation Maritime S.A. |
|
Latest data adjustment |
05 December 2015 |
