Westerschelde 06 December 2017 |
 |
 |
 |
||
| Antwerpen 22/05/15 | Westerschelde 18/05/18 | Westerschelde 18/05/18 |
|
Name |
WARBER |
|
Type |
General cargo dry ship - heavycargo |
|
IMO-number |
9467201 |
|
Call sign |
PILF |
|
Flag |
The Netherlands |
|
Port of registry |
Lemmer |
|
GT |
2.862 t |
|
DWT |
Summer: 4.114 t |
|
DWCC |
Summer/winter: 3.900 t |
|
NT |
1.295 t |
|
Light displacement |
1.747 t |
|
Number of 20ft containers |
60 |
|
Length |
94,70 m overall 91,84 m between perpendiculars |
|
Breadth |
13,40 m |
|
Draught |
Summer: 5,30 m |
|
Air draft |
23,00 m in ballast |
|
Freeboard |
Summer: 2.600 mm |
|
Depth |
7,80 m moulded |
|
Speed |
Max: 13,7 knots |
|
Built |
2010 |
|
Keel laid |
21/05/2008 |
|
Launch date |
02/04/2010 |
|
Date of completion |
13/08/2010 |
|
Builder |
Hexing Shipbuilding & Repair Yard Wenling China |
|
Yard number |
06-004 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Movable bulkheads |
2 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M25 - 4 stroke single acting 6 cylinder 255 x 400 mm combustion engine 2.010 kW / 2.733 bhp hp at 750 rpm Builder: Caterpillar Motoren GmbH & Co. KG |
|
Gearbox |
1x Resita-Renk reduction 4.42217:1 |
|
Propellers |
1x Screw propeller controllable pitch - 4 blades Diameter: 3.200 mm |
|
Boilers |
1x CHR Aalborg Industries 74,90 m² - 10,0 bar 1x CHO Aalborg Industries 122,00 m² - 10,0 bar |
|
Shaft generator |
1x 275 kVA - 220 kW |
|
Generators |
2x Sisu Diesel - Each 182 KW diesel engine at 1.500 rpm connected with Stamford generator each 175 kVA - 400 Volt 3 Phase each |
|
Emergency generator |
1x Sisu diesel generatorset 66 kVA - 53 kW - 102 hp |
|
Bow thruster |
1x 220 kW |
|
Number of holds |
1x Boxshaped, steelfloored Dimensions: 61,60 x 11,20 x 8,34 m |
|
Total capacity of holds |
Grain: 5.538 m³ / 195.573 ft³ |
|
Timber capacity |
5.500 m³ |
|
Number of hatches |
1 Dimensions: 61,60 x 11,20 m |
|
Hatch type |
Pontoon |
|
Tank capacities |
Fuel oil: 222,21 m³ Ballast water: 1.764 m³ Potable water: 38,3 m³ Marine diesel oil: 47,4 m³ Lub oil: 21,7 m³ |
|
Cargo gear |
Gearless |
|
Crew size |
7 |
|
Manager |
Wijnne & Barends' Cargadoors- en Agentuurkantoren B.V. Handelskade Oost 5 9934 AR Delfzijl The Netherlands |
|
Owner |
C.V. Warber Lemmer The Netherlands |
|
Registered owner |
V.O.F Warber |
|
Latest data adjustment |
05 September 2020 |
