Westerschelde 08 June 2014 |
|
Name |
OLGA |
|
Type |
Geared bulk carrier |
|
IMO-number |
9109548 |
|
Call sign |
A8YT8 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
11.121 t registered Suez: 11.541 t |
|
DWT |
Summer: 18.792 t Winter: 18.249 t |
|
NT |
6.859 t registered Panama: 9.364 t Suez: 9.893 t |
|
Length |
148,17 m overall |
|
Breadth |
22,80 m moulded |
|
Draught |
Summer: 9,30 m |
|
Moulded L x B x D |
135,95 x 22,80 x 12,20 m |
|
Registered L x B x D |
136,51 x 22,80 x 12,20 m |
|
Freeboard |
2.926 mm |
|
Depth |
12,20 m moulded |
|
Speed |
Max.: 16,5 knots Laden: 13,5 knots Ballast: 14,0 knots |
|
Built |
1996 |
|
Keel laid |
22.09.1995 |
|
Launch date |
08.12.1995 |
|
Date of completion |
23.02.1996 |
|
Builder |
Shikoku Dockyard Co. Ltd. |
|
Yard number |
878 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Main engine |
1x Mitsui-MAN B&W 8L42MC - 2 stroke single acting 6 cylinder 420 x 1.360 mm diesel engine 5.651 kW at 170 rpm Manufacturer: Mitsui Engineering & Shipbuilding Co., Ltd. Tamano Works |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 445 mm |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary Vertical boiler - 6,9 bar Evaporation: 2,09 t/h Manufacturer: Tortoise Engineering Co., Ltd. |
|
Generators |
4x Generators - 1.325 kVA |
|
Number of holds |
4 Hold 1: 24,30 x F 9,00 - A 22,80 m Hold 2: 26,30 x F 18,15 - A 22,80 m Hold 3: 26,30 x F 19,71 - A 22,80 m Hold 4: 26,30 x F 19,70 x F 19,70 - A 22,80 m |
|
Cargo hold capacity |
Grain: Hold 1: 4.819 m³ Hold 2: 6.169 m³ Hold 3: 6.176 m³ Hold 4: 6.047 m³ Total: 23.211 m³ Bales: Hold 1: 4.626 m³ Hold 2: 5.918 m³ Hold 3: 5.926 m³ Hold 4: 5.866 m³ Total: 22.336 m³ |
|
Number of hatches |
4 Hatch 1: 16,30 x 12,00 m Hatch 2-4: 19,50 x 12,00 m |
|
Type of hatch covers |
Folding type |
|
Max. permitted loads |
Tanktop: 15,0 t/m² |
|
Tank capacities |
Fuel oil: 1.262 m² Fresh water: 403 m² Water ballast: 5.053 m³ |
|
Cargo gear |
3x Cranes - SWL 30,0 t each |
|
Manager |
Johann M.K. Blumenthal GmbH & Co. KG |
|
Owner |
MS 'Olga' Schiffahrtsgesellschaft mbH & Co.KG |
|
Registered owner |
Ventura Maritime Company Limited |
|
Latest data adjustment |
08 April 2015 |
