Name

ROBIJN

Type

General cargo ship - Strengthened for heavy cargo - Equipped for carriage of containers

Single deck - open hatch fully box, double skinned

IMO-number

9423669

Call sign

PBEJ

Flag

The Netherlands

Port of registry

Delfzijl

GT

2.528 t

DWT

3.619 t

DWCC

Summer: 3.350 t

NT

1.053 t

Number of 20ft containers

157

Length

89,99 m overall

84,95 m between perpendiculars

Breadth

12,50 m extreme

Draught

5,30 m

Air draft

22,75 m

Freeboard

2.508 mm

Depth

8,00 m moulded

Speed

Service: 10,5 knots

Max: 13,5 knots

Built

2008

Keel laid

18/07/2007

Launch date

19/03/2008

Date of completion

22/08/2008

Builder casco

Leda Shipyard

Korcula

Croatia

Builder completion

Scheepswerf Peters B.V.

Haatlandhaven 1

8.263 AS Kampen

The Netherlands

Yard number

1210

Hull material

Steel

Hull type

Double skinned

Watertight compartments

3

Bulkheads

2x Moveable

Number of decks

1

Main engine

1x Wärtsilä 9L20 - 4 stroke single acting 9 cylinder 200x 280 mm combustion engine 1.800 kW / 2.446 hp at 1.000 rpm

Build: 19/02/2008

Builder: Wärtsilä NSD Nederland B.V., Zwolle - The Netherlands

Propeller

1x Controllable pitch propeller Scana Volda - aft at 191 rpm

Diameter: 2.700 mm

Number of blades: 4

Gearbox

1x Reduction gear Scana Volda ACG-680K 5.24:1

Electric installation voltage

400/230 V - 50 Hz

Shaft generator

Stamford HCM534D - 390 kVA

Generator

1x Sisu 645-DSBIG - 6 cylinder diesel engine 180 kW at 1.500 rpm connected with Stamford generator HCM434C 210 kVA

Emergency generator

1x Sisu 420-DSRG - 4 cylinder diesel engine 70 kW at 1.500 rpm connected with Stamford UCM274C generator 77 kVA

Bow thruster

1x Veth tunnel thruster, type VT-200 met E-motor 250 kW at 1.500 rpm

Number of holds

1

Hold dimensions: 60,00 x 10,30 x 8,15 m

Cargo hold capacity

Grain/bale: 4.927 m³ / 174.063 ft³

Hold ventilation

6x Air-changes per hour

Hold is fitted with dehumidifier system

Hatch

1

Hatch dimensions: 60,00 x 10,30 m

Hatches type

Pontoon

Cargo capacity

Grain: 4.927 m³

Tank capacities

Fuel oil: 250 m³

MGO: 38 m³

Water ballast: 1.466 m³

Potable water: 25 m³

Lifting equipment

1x Gantry crane

1x Store crane

Anchors

2

Weight: 1.305 kg each

Chain Length: 440,00 m

ISM manager

CV Scheepvaartonderneming van Donderen

Polarisweg 18

9933 HG Delfzijl

The Netherlands

Commercial manager

Wagenborg Shipping BV

Marktstraat 10

9934 KK Delfzijl

The Netherlands

Registered owner

Klaas van Donderen, A.C.T. van Donderen-van der Molen, Arthur Schwering, Delfzijl, Groningen - The Netherlands (CV Scheepvaartonderneming Robijn)

Delfzijl

The Netherlands

Previous owners

08/2008 - 01/2022 Klaas van Donderen, A.C.T. van Donderen-van der Molen, Arthur Schwering, Jamie Muylaert, Delfzijl - The Netherlands

Latest data adjustment

07 July 2022
