Name |
RICHELIEU |
|
Type |
Multi purpose cargo vessel - Strengthened for heavy cargoes - Containers cargoes in hold and on upperdeck Singledecker |
|
IMO-number |
9369526 |
|
Call sign |
ZDHS7 |
|
Flag |
Gibraltar |
|
Port of registry |
Gibraltar |
|
GT |
2.545 t |
|
DWT |
Summer: 3.817 t |
|
NT |
1.460 t |
|
Number of 20ft containers |
On deck: 68 In hold: 108 Total: 176 |
|
Number of 40ft containers |
On deck: 32 + 4 TEU TEU In hold: 45 + 15 TEU Total: 77 + 19 TEU |
|
Length |
88,60 m overall 84,99 m between perpendiculars |
|
Breadth |
12,50 m moulded |
|
Draught |
Summer: 5,42 m |
|
Keel to mast end |
24,80 m |
|
Depth |
7,00 m moulded |
|
Speed |
Max: 11,5 knots Service: 10,5 knots |
|
Built |
2007 |
|
Keel laid |
16/12/2004 |
|
Date of completion |
02/03/2007 |
|
Builder casco |
Tallinn Shipyard (BLRT Laevaehitus OU) Tallinn Estonia Yard number: Y9369526 |
|
Builder completion |
Damen Shipyards Bergum B.V. Bergum The Netherlands Yard number: 9362 |
|
Bulkheads |
2x Movable grain bulkheads with 8 positions |
|
Number of decks |
1 |
|
Main engine |
1x MaK 8M20 - 4 stroke 8 cylinder 200 x 300 mm combustion engine 1.520 kW / 2.067 hp at 1.000 rpm |
|
Propeller |
1x Fixed pitch propeller |
|
Generators |
1x Scania diesel generatorset 275 kW 1x Sisu diesel generatorset 150 kW |
|
Emergency generator |
1x Sisu diesel generatorset - 58 kVA |
|
Bow thruster |
1x 220 kW |
|
Number of holds |
1 62,70 x 10,10 x 8,43 m |
|
Cargo hold capacity |
Bale / grain: 5.248 m³ - 185.331 ft³ |
|
Number of hatches |
1 62,84 x 10,39 m |
|
Hatch cover type |
10x panels, lift away covers of pontoon type / electric hydraulic operated by gantry crane |
|
Hold ventilation |
6 Air-changes per hour |
|
Floor space |
Under deck: 1.613 m² / 16.590 ft² On deck: 651 m² / 6.998 ft² |
|
Strength |
Deck: 1,6 t/m² Tanktop: 15,0 t/m² |
|
Tank capacities |
Ballast: 1.384 m³ Fresh water: 55 t MGO: 44 m³ |
|
Lifting equipment |
1x Gantry crane - SWL 12,5 t |
|
Gear |
Gearless |
|
Accommodation |
7 persons, 6 cabins |
|
Commercial manager |
Briese Shipping BV Torenstraat 14 9679 BP Scheemda The Netherlands |
|
ISM manager |
Briese Dry Cargo Gmbh & Co Kg Hafenstrasse 12 26789 Leer Germany |
|
Registered owner |
Westeel Briese Schiffahrts Care of Briese Shipping BV Torenstraat 14 9679 BP Scheemda The Netherlands |
|
Sister ship |
12/2005 Milady - IMO 9319430 |
|
Renamed |
04/2022 Breb Trader Portugal, Madeira - Call sign: CQPE Owner: Neuwerk Breb Schifffahrts |
|
Latest data adjustment |
27 May 2022 |
