Name |
LADY ROSEBAY |
|
Type |
Refrigerated cargo carrier - Designed for carriage of containers |
|
IMO-number |
9412751 |
|
Call sign |
3FJA8 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
9.603 t registered |
|
DWT |
Summer: 10.601 t Winter: 10.137 t |
|
NT |
5.562 t registered |
|
Number of 20ft containers |
176 |
|
Reefer capacity |
100 |
|
Length |
143,00 m overall |
|
Breadth |
22,70 m moulded |
|
Draught |
Summer: 9,02 m Winter: 8,82 m |
|
Moulded L x B x D |
133,00 x 22,70 x 13,40 m |
|
Registered L x B x D |
134,17 x 22,70 x 13,40 m |
|
Freeboard |
Summer: 4.413 mm |
|
Depth |
13,40 m moulded |
|
Speed |
Max: 22,4 knots |
|
Built |
2010 |
|
Keel laid |
14/07/2009 |
|
Launch date |
14/11/2009 |
|
Date of completion |
11/03/2010 |
|
Builder |
Kitanihon Shipbuilding Co., Ltd. Hachinohe Japan |
|
Yard number |
508 |
|
Hull material |
Steel |
|
Main engine |
1x Mitsubishi 8UEC50LSII - 2 stroke single acting 8 cylinder 500 x 1.950 mm combustion engine 11.560 kW / 15.717 hp at 127,0 rpm Manufacturer: Akasaka Diesels Ltd., Shizuoka - Japan |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 520 mm |
|
Propellers |
1x Fixed $itch propeller |
|
Boilers |
1x Auxiliary vertical boiler- 8,0 bar Evaporation: 2,14 t/h Manufacturer: Miura Co., Ltd. |
|
Generators |
4x Generatorsets total 4.205 kVA |
|
Number of holds |
4 |
|
Cargo hold capacity |
Hold 1: 94.911 ft³ Hold 2: 152.291 ft³ Hold 3: 155.217 ft³ Hold 4: 150.194 ft³ Total: 552.613 ft³ / 6.061,5 m³ |
|
Pallets |
4.592 |
|
Number of hatches |
4 |
|
Compartments |
15 |
|
Temperature zones |
8 |
|
Min temp |
-25°C |
|
Tank capacities |
Fuel oil: 1.693 m³ Fresh water: 267 m³ |
|
Cargo gear |
2x Deck cranes - SWL 40,0 t each 2x Deck cranes - SWL 8,0 t each |
|
Crew |
19 |
|
ISM & commercial manager |
Santoku Senpaku Co., Ltd. 8th Floor Santoku Senpaku Building 26-9 Isoji 3-chome Minato-ku Osaka-Shi Japan |
|
Registered owner |
Lucretia Shipping SA c/o Santohu Co. Ltd. 8th Floor Santoku Senpaku Building 26-9 Isoji 3-chome Minato-ku Osaka-Shi Japan |
|
Previous owners |
2010 - 2015 St Ocean Shipping SA |
|
Latest data adjustment |
13 December 2022 |
