| Westerschelde 20 April 2016 |
 |
 |
 |
 |
 |
||||
| Westerschelde 12/04/12 | Westerschelde 11/10/13 | Westerschelde 11/10/13 | Westerschelde 03/11/16 | Westerschelde 18/08/20 | ||||
|
Name |
MARIANNE |
|
Type |
Liquefied gas tanker - LPG |
|
IMO-number |
9474539 |
|
Call sign |
ONKA |
|
Flag |
Belgium |
|
Port of registry |
Antwerpen |
|
Previous flag |
2009 - 2019 Hong Kong - China, Hong Kong - Call sign: VRFM5 |
|
GT |
3.493 t registered |
|
DWT |
Summer: 4.001 t |
|
NT |
1.048 t registered |
|
Length |
97,23 m overall |
|
Breadth |
16,50 m moulded |
|
Draught |
Summer: 5,42 m |
|
Moulded L x B x D |
89,90 x 16,50 x 7,20 m |
|
Registered L x B x D |
90,09 x 16,50 x 7,20 m |
|
Keel to mast end |
32,07 m |
|
Freeboard |
1.817 mm |
|
Depth |
7,20 m moulded |
|
Speed |
Max: 13,6 knots Service: 12,1 knots |
|
Built |
2009 |
|
Keel laid |
02/04/2009 |
|
Launch date |
03/06/2009 |
|
Date of completion |
09/09/2009 |
|
Builder |
Yamanishi Shipbuilding & Iron Works Ishinomaki Japan |
|
Yard number |
1079 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN-B&W/Makita 5L35MC - 2 stroke single acting 5 cylinder 350 x 1.050 mm combustion engine 2.700 kW / 3.668 hp at 210,0 rpm Build: 2009 Manufacturer: Makita Corporation, Takamatsu, Kagawa - Japan |
|
Propeller shaft |
1x Sea water lubrication shaft Diameter: 281 mm |
|
Propellers |
1x Screw propeller solid - aft at 210 rpm |
|
Generators |
2x main diesel generatorsets each 500 kVA - 400 kW - 599 hp |
|
Cargo tank capacity |
Liquid: 3.539 m³ |
|
Number of pumps |
2x Cargo pumps each 300 m³/h |
|
Max. pressure |
17,7 bar |
|
Min. temperature |
-10°C |
|
Tank capacities |
Fuel oil: 643 m³ Fresh water: 225 m³ Water ballast: 1.632 m³ |
|
Commercial manager |
Exmar Marine SA De Gerlachekaai 20 2000 Antwerpen Belgium |
|
ISM manager |
Exmar Shipmanagement NV De Gerlachekaai 20 2000 Antwerpen Belgium |
|
Registered owner |
Diana Ro Ltd. Care of Exmar Marine S.A. De Gerlachekaai 20 2000 Antwerpen Belgium |
|
Last data update |
30 September 2022 |
