| Zeebrugge 14 February 2011 |
 |
| Zeebrugge 14/02/11 |
|
Name |
MAGGIE M |
|
Previous names |
NP 325 |
|
Type |
Multi purpose vessel - Work boat pontoon |
|
Service |
Sea water outfalls, Dredging support, Port and harbour construction and other Marine construction duties |
|
Call sign |
2APP2 |
|
Flag |
United Kingdom |
|
Port of registry |
Greenock |
|
GT |
84 t |
|
DWT |
135 t |
|
NT |
91,87 t |
|
Length |
21,60 m overall 20,25 m between perpendiculars |
|
Breadth |
9,04 m over all |
|
Draft |
Dry: 1,80 m Loaded: 3,00 m |
|
Depth |
3,00 m |
|
Speed |
Cruising: 10,0 knots |
|
Built |
2008 |
|
Date of completion |
28.06.2008 |
|
Builder |
Neptune Marine Service BV |
|
Yard number |
NP 325 |
|
Hull material |
Steel |
|
Watertight compartments |
7 |
|
Continuous decks |
1 |
|
Main engine |
2x Mitsubishi S12 A2 - 4 stroke 12 cylinder internal combustion engine - 1.276 kW / 1.734 hp at 1.940 rpm Built: 2007 Builder: Mitsubishi Heavy Industries, Ltd. General Machiner, Sagamihara - Japan |
|
Propelling system |
2x Screw propeller solid |
|
Generators |
2x John Deere diesel generatorsets each 120 kVA - 96 kW - 92 hp |
|
Deck Equipment |
1x Remote Control Crane Heila Model HLRM 140-3SL 18,60 t at 7,53 m 13,50 t at 9,70 m 10,30 t at 11,87 m 8,00 t at 14,04 m 5,0 t Boom mounted winch |
|
Winches |
50 t anchor handling winch with split drum 10 t bridge controlled tugger winch Crane Mounted Winch |
|
Deck load |
150 t |
|
Deck area |
150 m² |
|
Bollard Pull |
20 t |
|
Owner |
Gareloch Support Services (Plant) Ltd. United Kingdom |
