Westerschelde 18 June 2016 |
 |
 |
 |
 |
|||
| Westerschelde 14/05/16 | Antwerpen 14/01/17 | Westerschelde 29/04/17 | WS 29/04/17 | |||
|
Name |
RIO TESLIN |
|
Previous names |
2004 Launch as: Rio Teslin 03/2004 - 12/2005 P&O Nedlloyd Teslin 12/2005 - 04/2012 Nedlloyd Teslin |
|
Type |
Cellular containership |
|
IMO-number |
9283693 |
|
Call sign |
A8JS6 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
26.833 t |
|
DWT |
Summer: 34.567 t |
|
NT |
12.743 t |
|
Number of 20ft containers |
In hold: 944 On deck: 1.612 Total: 2.556 |
|
Container capacity 14t |
1.850 |
|
Reefer capacity |
600 |
|
Length |
210,07 m overall 199,00 m between perpendiculars |
|
Breadth |
30,23 m extreme |
|
Draught |
11,50 m |
|
Depth |
16,70 m moulded |
|
Speed |
Max.: 22,0 knots |
|
Built |
2004 |
|
Keel laid |
11/11/2003 |
|
Launch date |
31/01/2004 |
|
Date of completion |
27/02/2004 |
|
Builder |
Hyundai Heavy Industries Co., Ltd. 1, Cheonha-dong, Dong-gu Ulsan, Kyongsang-namdo Republic of Korea |
|
Yard number |
H1490 |
|
Hull material |
Shipbuilding steel (standard) Higher tensile steel |
|
Hull type |
Double bottom |
|
Watertight bulkheads |
8 |
|
Continuous decks |
2 |
|
Main engine |
1x Wärtsilä-HHI 7RTA72U-B - 2 stroke single acting 7 cylinder 720 x 2.500 mm combustion engine Mcr 21.560 kW / 29.313 hp at 99,0 rpm Year of manufacture: 2008 Manufacturer: Hyundai Engine & Machinery Co., Ltd., Ulsan - Republic of Korea |
|
Propellers |
1x Solid propeller (keyless) - aft at 99,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 8,0 bar Heating surface: 35,0 m² 1x Steam boiler, exhaust gas heated - 8,0 bar Heating surface: 392,9 m² Year of manufacture: 2009 Manufacturer: KangRim Industries Co., Ltd. (3rd Factory) 40, Wongnam-dong Changwon Republic of Korea |
|
Electric installations |
4x Plants each 450 V - 2.133,3 kVA 1x Plant 450 V - 230 kVA 2x Plants each 24 V - 200 Ah 2x Plants each 24 V - 200 Ah 12x Plants each 24 V - 200 Ah 12x Plants each 24 V - 300 Ah |
|
Generators |
4x MAN-B&W 8L28/32H- 4 stroke 8 cylinder 280 x 320 mm diesel genihes each Mcr 1.980 kW connected with generators each 2.133,3 kVA / 450/230 Volt |
|
Emergency generator |
1x D 2866 TE diesel generatorset 230 kVA |
|
Batteries |
12x Batteries for UPS navigation each 300 Ah 12x Batteries for emergency lighting each 200 Ah 2x Batteries for start emergency engine each 200 Ah 2x Batteries for automation each 200 Ah |
|
Compressed air receivers |
2x Receivers each 5.000 litres - 30,0 bar 1x Receiver 250 litres - 30,0 bar 1x Receiver 200 litres - 8,8 bar 1x Receiver 2.000 litres - 8,0 bar |
|
Bow thruster |
1x Transverse tunnel thruster 1.000 kW / 1.360 bhp, forward |
|
Tank capacities |
Fuel oil: 4.005 m³ Diesel oil: 130 m³ Ballast: 9.457 m³ |
|
Anchor equipment |
3x Anchors weight each 9.300 kg Length: 660,00 m Diameter: 76 mm |
|
Cargo gear |
4x Cranes - SWL 40,0 t each |
|
Crew size |
27 |
|
Manager |
Ahrenkiel Steamship GmbH & Co. KG Palmaille 67 22767 Hamburg Germany |
|
Registered owner |
Rio Teslin OpCo GmbH & Co. KG Hamburg Germany |
|
Renamed |
2018 AS Palina Liberia, Monrovia - Call sign: A8JS6 Owner: Zweite "AS PALINA" Schifffahrtsgesellschaft mbH & Co. KG Manager: Wilhelmsen Ahrenkiel Ship Management |
|
Latest data adjustment |
18 April 2023 |
