Westerschelde 07 April 2015 |
 |
 |
 |
||
| Westerschelde 26/03/16 | Westerschelde 29/06/15 | Westerschelde 02805/15 | ||
|
Name |
MSC RAFAELA |
|
Type |
Cellular containership |
|
IMO-number |
9129885 |
|
Call sign |
3FWG6 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
Previous flag |
1996 - 1996 Italy |
|
GT |
42.307 t |
|
DWT |
Summer: 51.210 t |
|
NT |
22.638 t |
|
Number of 20ft containers |
3.300 |
|
Container capacity 14t |
2.900 |
|
Reefer capacity |
150 |
|
Length |
244,15 m overall 233,05 m between perpendiculars |
|
Breadth |
32,25 m |
|
Draught |
Max.: 13,70 m |
|
Freeboard |
5.325 mm |
|
Depth |
19,00 m |
|
Speed |
Max.: 22,6 knots |
|
Built |
1996 |
|
Keel laid |
30/01/1996 |
|
Launch date |
05/1996 |
|
Date of completion |
10/10/1996 |
|
Builder |
Fincantieri-Cantieri Navali Italiani S.p.A Ancona Italy |
|
Yard number |
5959 |
|
Hull material |
Ordinary steel |
|
Hull type |
Single hull |
|
Main engine |
1x Sulzer 7RTA84C - 2 stroke 7 cylinder 840 x 2.400 mm combustion engine 28.371 kW / 38.573 hp at 102,0 rpm |
|
Propellers |
1x Fixed pitch propeller- aft at 102,0 rpm |
|
Generators |
4x Diesel generatorsets each 1.525 kW |
|
Number of holds |
6 |
|
Cargo gear |
Gearless |
|
Commercial manager |
MSC - Mediterranean Shipping Company S.A chemin Rieu, 12-14 1208 Geneva Switzerland |
|
ISM manager |
Mediterranean Shipping Co., Srl Via Francesco Ciampa 29 80063 Piano di Sorrento NA Italy |
|
Registered owner |
Jacinia Holdings Inc. Care of MSC Mediterranean Shipping Co., SA chemin Rieu, 12-14 1208 Geneva Switzerland |
|
Previous owner & name |
1996 - 1996 MSC Rafaela - Elnav Esercizio e Locazione |
|
Latest data adjustment |
19 July 2023 |
