Name |
COSCO VIETNAM |
|
Previous names |
2011 - 03/2013 COSCO Vietnam 03/2012 - 06/2013 Alianca Itapoa |
|
Type |
Cellular containership - Panamax |
|
IMO-number |
9448815 |
|
Call sign |
VRID5 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hog Kong |
|
GT |
91.051 t |
|
DWT |
Summer: 102.875 t |
|
NT |
55.451 t |
|
Number of 20ft containers |
8.500 |
|
Container capacity 14t |
6.310 |
|
Reefer capacity |
700 |
|
Length |
334,07 m overall 319,00 m between perpendiculars |
|
Breadth |
42,87 m extreme |
|
Draught |
Max: 14,5 knots |
|
Depth |
24,80 m |
|
Speed |
Max: 25,6 knots |
|
Built |
2011 |
|
Keel laid |
11/10/2010 |
|
Launch date |
24/12/2010 |
|
Date of completion |
21/04/2011 |
|
Builder |
Hyundai Heavy Industries Co., Ltd. Ulsan South Korea |
|
Yard number |
2088 |
|
Hull material |
Higher tensile steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x Hyundai/MAN-B&W 11K98ME - 2 stroke single acting 11 cylinder 980 x 2.660 mm combustion engine 68.530 kW / 93.173 hp at 97,0 rpm Manufacturer: Hyundai Heavy Industries Co Ltd - South Korea |
|
Propellers |
1x Fixed pitch mono-block propeller- aft at 97,0 rpm |
|
Boilers |
1x Exhaust gas eEconomiser 1x Water tube auxiliary boiler |
|
Generators |
4x Hyundai/Himsen 6H32/40 - 4 stroke 6 cylinder 320 x 400 mm diesel engines each 2.870 kW connected with generators each 2.750 kW Builder: Hyundai Engine & Machinery Co. Ltd. |
|
Emergency generator |
1x Hyundai/Doosan V/AD 158 diesel generatorset |
|
Bow thruster |
1x Tunnel thruster 2.500 kW / 3.399 bhp, forward |
|
Number of holds |
9 |
|
Tank capacities |
Ballast: 23.928,1 m³ |
|
Anchor equipment |
Length: 742,50 m Diameter: 107 mm |
|
Cargo gear |
Gearless |
|
Crew |
27 |
|
Manager |
Seaspan Ship Management Ltd. Suite 2600 - 200, Granville Street Vancouver BC V6C 1SA Canada |
|
Operator |
COSCO Container Lines Co., Ltd. (“COSCON”) COSCO Plaza, 378, Dongdaming Lu, Hongkou Qu Shanghai, 200080 China |
|
Registered owner |
Seaspan Corporation Unit 2 – 16th Floor, W668 Building Nos. 668 Castle Peak Road, Cheung Sha Wan, Kowloon Hong Kong |
|
Latest data adjustment |
03 March 2022 |
