Name
|
MORNING LADY
|
|
Korean name
|
모닝 레이디
|
|
Type
|
Roll-On/Roll-Off carrier vehicles carrier
PCC - Pure Car Carrier
|
|
IMO-number
|
9445980
|
|
Call sign
|
D8ML
|
|
Flag
|
South Korea
|
|
Port of registry
|
Jeju
|
|
Previous flags
|
2010 - 2020 Republic of Panama, Panama City - Call sign: 3FKC3
|
|
GT
|
70.853
|
|
DWT
|
27.343 t
|
|
NT
|
25.275
|
|
Length
|
233,38 overall
|
|
Breadth
|
32,26 m
|
|
Draught
|
10,02 m
|
|
Reg. dimensions L x B x D
|
225,52 x 32,26 x 20,11 m
|
|
Rule dimensions L x B x D
|
222,60 x 32,26 x 20,11 m
|
|
Freeboard
|
Summer: 3/020 mm
|
|
Depth
|
20,11 m
|
|
Speed
|
19,6 knots
|
|
Built
|
2010
|
|
Keel laid
|
08/02/2010
|
|
Launch date
|
30/04/2010
|
|
Date of completion
|
20/07/2010
|
|
Builder
|
Hyundai Heavy Industries Co., Ltd.
Ulsan
South Korea
|
|
Yard number
|
2053
|
|
Hull material
|
Steel
|
|
Watertight bulkheads
|
3
|
|
Main engine
|
1x MAN-B&W/HHI 7S60MC-C8 - 2 stroke single acting 7 cylinder 600 x 2.400 mm combustion engine 14.280 kW / 19.415 hp at 105,0 rpm
Build: 01/12/2009
Builder: Hyundai Heavy Industries Co., Ltd., Engine & Machinery Division, Ulsan - South Korea
|
|
Propellers
|
1
|
|
Boilers
|
1x Auxiliary Boiler water tube boiler
Pressure: 8,8 kg/cm²
Heating Surface: 24,0 m²
1x Economizer EGE
Pressure: 11,7 kg/cm²
Heating Surface: 249,0 m²
Build: 01/02/2010
Builder: Kangrim Heavy Industrial Co., Ltd., Changwon - South Korea
|
|
Generators
|
3x Main diesel generatorsets each 1.662 kVA - 450 Volt
|
|
Emergency generator
|
1x Sisu 634 DSBIG diesel generatorset
|
|
Number of cars
|
8.100
|
|
Tank capacities
|
Fuel oil: 5.045,2 m³
Fresh water: 300,5 m³
Water ballast: 12.067,7 m³
|
|
Crew
|
26
|
|
Commercial manager
|
EUKOR Car Carriers Incorporated
300 Interpace Parkway, Ste A300 Parsippany
NJ 07054 New Jersey
United States Of America
|
|
ISM manager
|
Wilhelmsen Ship Management (Korea) Ltd.
10th Floor, Marine Center Building, 52, Chungjang-daero 9beon-gil, Jung-gu,
Busan, 48936
South Korea
|
|
Registered owner
|
EUKOR Car Carriers Incorporated
300 Interpace Parkway, Ste A300 Parsippany
NJ 07054 New Jersey
United States Of America
|
|
Latest data adjustment
|
03 January 2026
|
