Spijkenisse, The Netherlands 26 May 2013 |
|
Name |
EN AVANT 1 |
|
Previous names |
2005 - 04.2011 DMS World |
|
Type |
Tug - Damen Stan Tug 2608 Harbour towage - seagoing towage - marine salvage -dredging assistance - anchor handling |
|
IMO-number |
9342102 |
|
Call sign |
PHDP |
|
Flag |
The Netherlands |
|
Port of registry |
Dordrecht |
|
GT |
186 t registered |
|
Displacement |
240 t Empty tanks |
|
NT |
56 t registered |
|
Length |
26,09 m overall 23,96 m between perpendiculars |
|
Breadth |
7,94 m overall |
|
Draught |
Min.: 3,85 m Max.: 4,05 m |
|
Depth |
4,05 m |
|
Speed |
12,5 knots |
|
Built |
2005 |
|
Date of completion |
01.09.2005 |
|
Builder |
Damen Shipyard Gorinchem |
|
Yard number |
509808 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Continuous decks |
1 |
|
Main engine |
2x Caterpillar type 3512B TA HD/B - 4 stroke 12 cylinder 170 x 190 mm internal combustion engine - output 2.610 kW / 3.546 hp total at 1.600 rpm Built: 2005 Builder: Caterpillar Inc. |
|
Propulsion |
2x Kaplan sScrew propeller solid pitch - at 248 rpm in nozzle Diameter: 2.350 mm |
|
Gearbox |
2x Reintjes type WAF 772 - 6.44:1 |
|
Electric installations |
Power voltage: 380 V Lighting voltage: 220 V |
|
Generators |
2x Caterpillar type 2204 B T diesel engines each 141 hp coupled with generator each output 125 kVA / 100 kW each, 50 Hz 230/400 V, 3 Phase |
|
Deck equipment |
Anchor winch Towing winch P=20 t at 10 m/min., B= 100,0 t Tugger winch hydraulic 4,5 t at 15 m/min., remote controlled Gob eye: flush in deck (max. SWL 20,0 t) Stern roller 2.000 mm, diameter 711 mm, SWL 30,0 t |
|
Towing equipment |
Towing winch: Kraaijeveld, hydraulic Rated pull: 20,0 t - 10m/min Brake holding: 100,0 t Towing wire 650,00 m diameter 44 mm |
|
Free deck area |
50 m² |
|
Deck strenght |
2,0 t/m² |
|
Bollard pull |
48,3 t |
|
Salvage pumps |
Salvage and FIFI equipment available |
|
Tank capacities |
Fuel oil: 80,10 m³ Fresh water: 12,20 m³ Lub oil: 1,90 m³ Dirty oil: 1,90 m³ Sewage: 1,80 m³ Water ballast: 19,40 m³ |
|
Deck crane |
1x Heila 25-4SL (remote controlled) 1,6 t at 12,94 m 2,0 t at 10,94 m 2,5 t at 8,90 m 3,3 t at 6,89 m 5,0 t at 4,89 m 9,0 t at 2,79 m |
|
Accommodation |
Heated and air-conditioned living spaces for 7 persons, consisting of galley, mess-room, captain's cabin, 1st officer cabin on main deck Below deck 2x double crew cabins, C.E. Cabin and sanitary facilities |
|
Crew |
604.2011 |
|
Navigation & communication Equipment |
GMDSS Area: A3 Searchlights: Pesch 1000 W Compass: 1x Kotter type/ 1x gyro compass Radar system: Furuno FR 1505 mk III GPS: Furuno GP - 90 Autopilot: Radio Holland Seapilot 75 Echo sounder: Furuno FCV-582L VHF radio / telephone: 2x Sailor RT 4822, 25 Watt VHF handheld: 2x Axis-50 NAVTEX: Furuno NAV-NX500 Communication: Inmarsat C / SSB / phone |
|
Manager |
Muller Dordrecht Merwekade 82-83 |
|
Operator |
Muller Dordrecht Muller Zwaar Transport BV Merwekade 82 3300 AK Dordrecht The Netherlands |
|
Owner |
Tebra Beheer BV |
|
Latest data adjustment |
10 August 2014 |
