Westerschelde 19 Novemebr 2018 |
 |
 |
 |
 |
|||
| Westerschelde 19/11/18 | Westerschelde 26/04/19 | Westerschelde 23/04/19 | Vlissingen 23/04/19 | |||
|
Name |
NOTUS EXPRESS |
|
Previous names |
1999 - 07/2007 Stril Supplier 07/2007 - 2017 Siem Supplier 2017 - 2017 Karadeniz Powership Sir Patrick |
|
Type |
Tug - Platform supply vessel |
|
IMO-number |
9186601 |
|
Call sign |
OXDR2 |
|
Flag |
Denmark |
|
Port of registry |
Fredericia |
|
Previous flags |
1999 - 2018 Norway, Aalesund - Call sign: LJKB3 |
|
GT |
3.917 t |
|
DWT |
3.037 t |
|
NT |
1.332 t |
|
Length |
83,70 m overall 76,20 m between perpendiculars |
|
Breadth |
19,70 m extreme |
|
Draught |
Max: 6,10 m |
|
Depth |
7,45 m |
|
Speed |
Max: 15,5 knots Economic: 10,0 knots |
|
Built |
1999 |
|
Keel laid |
26/06/1998 |
|
Launch date |
08/01/1999 |
|
Date of completion |
26/04/1999 |
|
Builder casco |
De Hoop Heusden Heusden The Netherlands Yard number: 1032 |
|
Builder completion |
YVC Ysselwerf B.V. Capelle a/d IJssel The Netherlands Yard number: 273 |
|
Hull material |
Steel |
|
Bulkheads |
Transverse: 5 |
|
Main engine |
2x Caterpillar 3516B DITA each 1.825 kW at 1.800 rpm / 690 Volt 60 Hz 2x Caterpillar 3512B DITA each 1.360 kW at 1.800 rpm / 690 Volt 60 Hz |
|
Propellers |
2x Kamewa propulsion thrusters, azimuth |
|
Shaft generator |
2x 2.300 kW each |
|
Auxiliary generator |
2x Caterpillar 3408 DITA diesel generatorset each 450 kW |
|
Bow thruster |
1x Kamewa 2200-CP-KL - 883 kW |
|
Bow azimuth |
1x Aquamaster UL1201 |
|
Stern azimuth |
2x Aquamaster compass thruster CRP15 |
|
Deck storage |
480 m² work deck area 160 m² garage deck area 160 m² shelter deck area 200 m² under deck area |
|
Max cargo capacity |
Deck cargo: Up te 950 m² Deck strength: 5,0 t/m² MGO: 1.336 m³ - Discharge rate: 2x 250 m³/h Fresh water: 1.070 m³ - Discharge rate: 2x 150 m³/h Mud: 642 m³ - Discharge rate: 3x 100 m³/h Brine: 642 m³ - Discharge rate: 2x 100 m³/h |
|
Tank capacities |
Ballast: 724 m³ |
|
Accommodation |
Cabins: 27 Bunks: Up to 50 Changing rooms: 2 Offices: 2 Duty mess |
|
Navigation equipment |
1x 10 cm ARPA radar type Furuno RDP/115A 2x 3 cm ARPA radar type Furuno RDP/1124 1x Electronic chart system - Transan NS 1x Anschütz Gyro 1x Echosounder type Skipper ED-162 1x Skipper GDS 100 echosounder 1x DGPS type Seatex DPS 100 1x DGPS type Navigator MK10 1x GPS type Seatex DPS 100 1x Auto pilot Anschütz Pilostar D |
|
Communication equipment |
GMDSS area: A1 + A2 + A3 VHF: JRC JHS-32A UHF: Motorola MT2100 Satellite: V-Sat Mobile phone: GSM Telefax: GSM Sat TV: Sea Tel |
|
Manager |
A1 Offshore Solutions ApS Gronlandsvej 10 5700 Svendborg Denmark |
|
Owner |
A1 Carrier Express APS Denmark |
|
Renamed |
2020 Wilson Arctic Denmark, Esbjerg - Call sing: OXDR2 Owner: Wilson Offshore A/S Manager: World Marine Offshore A/S |
|
Latest data adjustment |
15 December 2021 |
