Westerschelde 01 October 2018 |
 |
 |
 |
 |
|||
| Westerschelde 10/09/18 | Antwerpen 07/05/19 | Antwerpen 07/05/19 | Westerschelde 29/07/19 | |||
|
Name |
SKS MOSEL |
|
Type |
Oil tanker/Ore/ bulk |
|
IMO-number |
9240433 |
|
Call sign |
LAXB5 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
GT |
70.933 t registered |
|
DWT |
Summer: 120.670 t |
|
NT |
33.583 t registered |
|
Light displacement |
21.730 t |
|
Length |
249,97 m overall 239,00 m between perpendiculars |
|
Breadth |
44,04 m extreme |
|
Draught |
Max: 15,72 m |
|
Keel to mast end |
48,66 m |
|
Depth |
23,20 m |
|
Speed |
Max: 15,2 knots 12,0 knots laden Economic: 10,0 knots laden |
|
Built |
2003 |
|
Keel laid |
10/12/2002 |
|
Launch date |
09/03/2003 |
|
Date of completion |
10/06/2003 |
|
Builder |
Hyundai Heavy Industries Co., Ltd. Ulsan South Korea |
|
Yard number |
1424 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Bulkheads |
Transverse: 12 Longitudinal: 2 |
|
Main engine |
1x Hyundai/MAN-B&W 5S70MC-C - 2 stroke 5 cylinder 700 x 2.800 mm combustion engine 15.519 kW / 21.100 hp at 91,0 rpm Manufacturer: Hyundai Engine & Machinery Co., Ltd.(B&W), Ulsan - South Korea |
|
Propellers |
1x Fixed pitch mono-block propeller |
|
Boilers |
Auxiliary boiler, exhaust gas heated Manufacturer: KangRim Industries. Co., Ltd. Auxiliary boiler, oil/gas fired Manufacturer: Aalborg Industries A/S |
|
Generators |
3X MAN-B1W 8L23/30 main diesel generatorsets |
|
Emergency generator |
1x Cummins 6CTA 8.3 diesel generatorset |
|
Cargo tank capacity 98% |
132.168 m³ excl. slops |
|
Slop tank capacity 98% |
1.471,2 m³ |
|
Total tank capacity 98% |
133.639,2 m³ |
|
Segregation |
3 |
|
Pumps |
9x Framo deepwell cargo pumps each 1.800 m³/h |
|
Manifolds |
Bow centre manifolds: 122,87 m |
|
Number of holds |
9 |
|
Cargo hold capacity |
Grain: 134.865 m³ |
|
Number of hatches |
9 Hatch 1: 10,25 m long x 15,12 m wide Hatches 2/4/5/7/8: 12,30 m long x 20,16 m wide Hatches 3/9: 11,275 m long x 20,16 m wide Hatch 6: 10,25 m long x 20,16 m wide |
|
Hatch covers type |
Hydraulic side-rolling |
|
Pumps |
9x Framo deepwell cargo pumps each 1.800 m³/h |
|
Tank capacities |
Ballast: 69.816,2 m³ |
|
Anchor equipment |
Length: 742,50 m Diameter: 95 mm |
|
Lifting equipment |
1x Crane - SWL 15,0 t |
|
ISM & commercial manager |
OSM Bergen Tank AS Sandsliåsen 46 5254 Sandsli Norway |
|
Registered owner |
Jebsen Group AS, 5015 Bergen - Norway Care of OSM Bergen Tank AS Sandsliasen 46 5254 Sandsli Norway |
|
Group |
SKS - Part of Kristian Gerhard Jebsen Group Zander Kaaes gate 7 5015 Bergen Norway |
|
Renamed |
11/2021 Sabaek Republic of Panama, Panama City - Call sign: 3E2021 Owner: Sabaek General Trading Co. W.L.L. - Kuwait Manager: Sea Bright Ship Management & Operation LLC - Dubai |
|
Latest data adjustment |
05 September 2024 |
