Westerschelde 02 February 2017 |
 |
 |
 |
 |
|||
| Westerschelde 14/01/17 | Antwerpen 26/05/16 | Antwerpen 26/05/16 | Westerschelde 23/05/16 | |||
|
Name |
SKS DRIVA |
|
Type |
Crude / Oil products tanker |
|
IMO-number |
9428970 |
|
Call sign |
C6GG7 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
Previous flags |
2010 - 05/2023 Norway, Bergen - Call sign: LAIV7 |
|
GT |
65.830 t |
|
DWT |
Summer: 119.456 t |
|
NT |
37.162 t |
|
Length |
249,99 m overall 239,00 m between perpendiculars |
|
Breadth |
45,04 m extreme |
|
Draught |
Summer: 15,22 m |
|
Keel to mast end |
49,00 m |
|
Depth |
21,50 m moulded |
|
Speed |
15,2 knots |
|
Built |
2010 |
|
Keel laid |
26/10/2009 |
|
Launch date |
17/12/2009 |
|
Date of completion |
30/03/2010 |
|
Builder |
Hyundai Samho Heavy Industries Co., Ltd. Samho South Korea |
|
Yard number |
S381 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN-B&W/HHI 6S70ME-C - 2 stroke 6 cylinder combustion engine 16.350 kW / 21.360 bhp |
|
Propellers |
1x Mono-block propeller Builder: HHI, Engine & Machinery Division |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated (Economizer) Builder: Kangrim Heavy Industries 1x Auxiliary boiler, oil/gas fired Builder: Aalborg |
|
Generators |
3x Doosan 5L28/32H diesel generatorsets each 1.055 kW Builder: Doosan Engine Co., Ltd. |
|
Emergency generator |
1x Cummins NTA 855 D(M) diesel generatorset 288 kW Builder: Cummins India Limited |
|
Number of tanks |
12 |
|
Cargo tank capacity 98% |
131.819,02 m³ excl. slops |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
2.826,13 m³ |
|
Total tank capacity 98% |
134.645,15 m³ |
|
Segregation |
6 |
|
Tank coating |
Pure Epoxy |
|
Pumps |
12x FRAMO Deepwell cargo pumps 1.500 m³/h each |
|
Slop tank pumps |
2x Framo Deepwell pumps 600 m³/h each |
|
Manifolds |
Distance between manifold centres: 2,50 m Centre manifold - bow: 122,80 m Centre manifold - stern: 127,20 m |
|
Tank capacities |
Ballast: 44.263,8 m³ |
|
Anchor equipment |
Length: 715,00 m Diameter: 92 mm |
|
Lifting equipment |
2x Cranes - SWL 15,0 t each |
|
Manager |
OSM Bergen Tank AS |
|
Operator |
SKS Tankers Holding AS Zander Kaaes gate 7 NO-5015 Bergen Norway |
|
Registered owner |
SKS Shipowning 2 Ltd. |
|
Latest data adjustment |
08 October 2024 |
