Westerschelde 25 March 2016 |
 |
 |
 |
 |
|||
| Westerschelde 25/03/16 | Westerschelde 28/04/18 | Westerschelde 28/04/18 | Westerschelde 28/04/18 | |||
|
Name |
HAFNIA HOPE |
|
Previous names |
2007 - 07/2014 Mount Hope |
|
Type |
Chemical tanker |
|
IMO-number |
9360415 |
|
Call sign |
9V3230 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
Previous flags |
01/2007 - 02/2015 Cyprus, Limassol |
|
GT |
22.521 t registered Suez: 23.599,84 t |
|
DWT |
Summer: 40.009 t |
|
NT |
11.214 t registered Panama: 18.768,44 t Suez: 20.698,37 t |
|
Length |
181,78 m overall 173,00 m between perpendiculars |
|
Breadth |
27,42 m extreme |
|
Draught |
Summer: 11,89 m Winter: 11,68 m |
|
Air draft |
Lightship: 43,91 m Normal ballast: 38,03 m At loaded summer deadweight: 34,35 m |
|
Keel to masthead |
46,25 m |
|
Freeboard |
Summer: 5.007 mm Winter: 5.212 mm Light ship: 14,59 m |
|
Depth |
16,90 m moulded |
|
Speed |
15,0 knots ballast 14,5 knots laden |
|
Built |
2007 |
|
Keel laid |
03/07/2006 |
|
Launch date |
13/09/2006 |
|
Date of completion |
31/01/2007 |
|
Builder |
Saiki Heavy Industries Co., Ltd. 5-37 Tsuruya-Machi 2-Chome Saiki City Oita 876 Saiki City, 876 Japan |
|
Yard number |
1157 |
|
Hull material |
High strength steel Ordinary strength steel |
|
Hull type |
Double hull |
|
Bulkheads |
Water tight: 3 Oil tight: 12 |
|
Main engine |
1x Mitsubishi 6UEC 52LS - 6 cylinder 520 x 1.850 mm combustion engine 7.980 kW at 120,0 rpm Manufacturer: Akasaka Diesel Limited. (Mitsubishi Heavy Ind., Ltd.) |
|
Propellers |
1 Manufacturer: Nakashima Propeller Co., Ltd. Tamashima Works |
|
Boilers |
1x Auxiliary boiler (vertical oil fired) -8,0 bar 1x Exhaust gas boiler - 7,0 bar Manufacturer: Osaka Boiler Mfg.Co.,Ltd. |
|
Generators |
3x Yanmar 6N18 (A) L-V main diesel generatorsets each 600 kW Manufacturer: Nishishiba Electric Co., Ltd. |
|
Bow thruster |
1x 884 bhp |
|
Number of cargo tanks |
12 |
|
Cargo tank capacity 98 |
Seg#1: 5.731,79 m³ (No1 P-S) Seg#2: 7.082,12 m³ (No2 P-S) Seg#3: 7.171,50 m³ (No3 P-S) Seg#4: 7.174,59 m³ (No4 P-S) Seg#5: 7.189,02 m³ (No5 P-S) Seg#6: 6.625,63 m³ (No6 P-S) Total: 40.974,65 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
1.258,79 m³ |
|
Pumps |
12x Centrifugal cargo pumps 500 m³/h each 2x Centrifugal cargo pumps 200 m³/h each 1x Centrifugal cargo pump 100 m³/h2x ballast pumps 600 m³/h each |
|
Number of tanks |
Ballast: 17 Lubricating oil: 14 Diesel oil: 9 Fresh water: 8 Fuel oil: 7 Waste water: 6 Sludge: 5 Chain: 2 Slop: 2 |
|
Tank capacities 100% |
Diesel Oil: 189,28 m³ Freshwater: 335,55 m³ Fuel Oil: 1.254,45 m³ Lube Oil: 134,73 m³ Tank Ballast: 16.270,97 m³ |
|
Manifolds |
Bow to centre manifold: 90,88 m Stern to centre manifold: 90,90 m Distance bridge front to centre of manifold: 59,00 m Distance between cargo manifold centres: 2.000 mm Distance ships rail to manifold: 4.440 mm Distance manifold to ships side: 4.640 mm Top of rail to centre of manifold: 700 mm Distance main deck to centre of manifold: 1.900 mm Spill tank grating to centre of manifold: 950 mm |
|
Lifting equipment |
1x Hose handling crane - SWL 10,0 t Manufacturer: Mitsubishi Heavy Ind. Ltd. 1x Provision crane - SWL 2,5 t Manufacturer: Mansei Industry Co.,Ltd. |
|
Technical operator |
Donnelly Tanker Management Ltd. 44-46, Vouliagmenis Avenue 16673 Athens Greece |
|
Commercial operator |
Hafnia Handy Pool Management ApS Tuborg Boulevard 5 DK-2900 Hellerup Denmark Denmark |
|
Registered owner |
Hafnia Tankers Shipholding Singapore Pte., Ltd. 159 Telok Ayer Street, Singapore 068614 Singapore Republic of Singapore |
|
Latest data adjustment |
13 January 2021 |
