Westerschelde 03 December 2016 |
 |
 |
 |
||
| Westerschelde 03/12/16 | Westerschelde 18/04/17 | Westerschelde 18/04/17 | ||
|
Name |
KIBAZ |
|
Previous names |
01/2004 - 01/2016 Biazo |
|
Type |
Oil products tanker |
|
IMO-number |
9263916 |
|
Call sign |
V7RB3 |
|
Flag |
Marshall Island |
|
Port of registry |
Majuro |
|
Previous flags |
01/2004 - 01/2016 Republic of Panama, Panama City - Call sign: HPTJ |
|
GT |
28.517 t registered Panama: 23.686,9 t Suez: 29.464,4 t |
|
DWT |
Summer: 47.094 t |
|
NT |
12.385 t registered Panama: 23.686,9 t Suez: 25.963,98 t |
|
Length |
182,50 m overall 172,00 m between perpendiculars |
|
Breadth |
32,20 m moulded |
|
Draft |
12,65 m |
|
Freeboard |
6.464 mm |
|
Depth |
19,10 m moulded |
|
Speed |
Max: 16,4 knots Wervice: 15,3 knots |
|
Built |
2004 |
|
Keel laid |
09/05/2003 |
|
Launch date |
29/07/2003 |
|
Delivery date |
09/01/2004 |
|
Builder |
Onomichi Dockyard Co., Ltd. 1005, Sanba-Cho, Onomichi City, Hiroshima Pref., 722-0052 Japan |
|
Yard number |
495 |
|
Hull material |
High strength steel |
|
Hull type |
Double hull |
|
Bulkheads |
Water tight: 1 Oil tight: 14 |
|
Continuous decks |
1 |
|
Main engine |
1x Mitsui/MAN-B&W 6S50MC - 6 cylinder 500 x 1.810 mm combustion engine Mcr 8.580 kW / 11.665 hp at 127,0 rpm Manufacturer: Mistui Engineering & Shipbuilding Co., Ltd., Tamano - Japan |
|
Propellers |
1x Fixed pitch propeller - aft at 127,0 rpm Manufacturer: Nakashima Propeller Co., Ltd. |
|
Boilers |
1x Exhaust gas economizer - 22,0 bar Manufacturer: Osaka Boiler Co., Ltd. 1x Auxiliary water tube boiler - 18,0 bar Manufacturer: Mitsubishi Heavy Ind. Nagasaki Works |
|
Generators |
3x Daihatsu 5DK-20 - 4 stroke 5 cylinder 200 x 300 mm diesel engine each Mcr 420 kW connected with generators each 370 kW Manufacturer: Nishishiba Electric Co., Ltd. |
|
Number of cargo tanks |
17 |
|
Cargo tank capacity |
100%: 53.608,3 m³ 98%: 50.333 m³ |
|
Slop tank capacity 98% |
2.076 m³ |
|
Number of pumps |
4x Cargo pumps each 1.000 m³/h |
|
Number of tanks |
Ballast: 16 Fuel oil: 5 Fresh water: 4 Waste water: 3 Diesel oil: 2 Lubricating oil: 2 Chain: 2 |
|
Tank capacities |
Diesel Oil: 132,4 m³ Freshwater: 460,3 m³ Fuel Oil: 1.696,4 m³ Lube Oil: 30,9 m³ Tank Ballast: 21.354,4 m³ |
|
Lifting equipment |
1x Hose handling crane - SWL 10,0 t Manufacture: Mitsubishi Heavy Ind./Oriental Precision & Engineering Co., Ltd. 1x Provision crane - SWL 2,0 t Manufacture: Mansei Industry |
|
Crew size |
19 |
|
Manager |
Kibaz Shipping LP Trust Company Complex Ajeltake Island Majuro Marshall Islands |
|
Operator |
V.Ships India |
|
Registered owner |
Kibaz Shipping LP |
|
Group |
Zenith Shipping Group |
|
Renamed |
11/2022 Soyia Liberia, Monrovia - Call sign: 5LIZ4 Owner: Peposo Maritime SA Operator: Flynn Ventures Ltd. |
|
Latest data adjustment |
29 April 2023 |
