| Westerschelde 15 April 2014 |
 |
 |
|
| Westerschelde 26/05/16 | Westerschelde 23/09/16 | |
|
Name |
CONTI HUMBOLDT |
|
Type |
Tank for oil & chemicals - Handysize |
|
IMO-number |
9391414 |
|
Call sign |
A8QQ5 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
23.403 t |
|
DWT |
Summer: 37.602 t |
|
NT |
9.940 t Suez: 21.003 t Panama: 19.493 t |
|
Length |
184,32 m overall 176,00 m between perpendiculars |
|
Breadth |
27,43 m extreme 27,30 m moulded |
|
Draught |
Summer: 11,32 m |
|
Depth |
17,20 m |
|
Keel to mast end |
46,60 m |
|
Speed |
Max: 15,5 knots |
|
Built |
2008 |
|
Keel laid |
21/07/2008 |
|
Launch date |
06/11/2008 |
|
Date of completion |
10/12/2008 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. Ulsan South Korea |
|
Yard number |
H2060 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight bulkheads |
8 |
|
Continuous decks |
1 |
|
Main engine |
1x Hyundai/MAN-B&W 6S46MC-C - 6 cylinder combustion engine 7.860 kW / 10.686 hp Starter type: Compressed air direct |
|
Propellers |
1x Mono-block fixed pitch propeller Manufacturer: Hyundai Heavy Industries Co., Ltd. |
|
Boilers |
1x Steam boiler, exhaust gas heated -9,0 bar Heating Surface: 110,0 m² 1x Steam boiler, oil fired - 9,0 bar Heating Surface: 110,0 m² Manufacturer: Alfa Laval Qingdao Ltd. |
|
Generators |
3x Hyundai 5H21/32 main diesel generatorsets each 912,5 kVA |
|
Emergency generator |
1x Diesel generatorset 120 kVA |
|
Compressed air receivers |
2x Receivers each 3.500 litres - 30,0 bar 1x Receiver 250 litres - 0,0 bar 1x Receiver 1.500 litres - 8,0 bar 1x Receiver 300 litres - 8,0 bar |
|
Number of tanks |
12 + 2 slop tanks |
|
Cargo tanks 98% |
40.805 |
|
Slop tanks 98% |
1.054 m³ |
|
Total tank capacity 98% |
41.859 m³ |
|
Tank coating |
Epoxy |
|
Pumps |
12x Framo Deepwell cargo pumps each 500 m³/h 2x Ballast pumps each 750 m³/h |
|
Manifolds |
Bow centre manifolds: 92,72 m |
|
Tank capacities |
Ballast: 18.061,6 m³ |
|
Anchor equipment |
3x Anchors weight each 7.350 kg Length: 605,00 m Diameter: 66 mm |
|
Lifting equipment |
1x Deck crane - SWL 10,0 t 1x Provision crane - SWL 2,0 t |
|
Crew size |
25 |
|
Manager |
NSB Niederelbe Schiffahrtsgesellschaft mbH & Co. |
|
Operator |
UTP - United Product Tankers GmbH & Co. KG Rödingsmarkt 20 20459 Hamburg Germany |
|
Registered owner |
Conti 150. Schifffahrts-GmbH & Co. KG MT "CONTI HUMBOLDT" |
|
Renamed |
2019 - 2023 Nordic Humboldt Liberia, Monrovia - Call sign: A8QQ5 2023 Bronx Liberia, Monrovia - Call sign: A8QQ5 Owner: Cadet Blue Shipping Ltd. Operator: IMS S.A. |
|
Latest data adjustment |
16 October 2023 |
