Westerschelde 30 October 2019 |
 |
 |
 |
 |
 |
||||
| Westerschelde 20/02/16 | Westerschelde 20/02/16 | Westerschelde 15/06/16 | Westerschelde 14/05/20 | Westerschelde 14/05/20 | ||||
|
Name |
STEN AURORA |
|
Type |
Tanker for oil & chemicals |
|
IMO-number |
9318565 |
|
Call sign |
LAKI6 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
GT |
11.935 t |
|
DWT |
Summer: 16.596 t |
|
NT |
5.141 t |
|
Length |
144,23 m overall 133,75 m between perpendiculars |
|
Breadth |
23,18 m extreme 23,00 m moulded |
|
Draught |
8,90 m |
|
Keel to top of mast |
44,50 m |
|
Freeboard |
3.523 mm |
|
Depth |
12,41 m |
|
Speed |
16,0 knots |
|
Built |
2007 |
|
Keel laid |
24/09/2006 |
|
Launch date |
06/02/2007 |
|
Date of completion |
17/09/2007 |
|
Builder |
Jiangnan Shipyard (Group) Co., Ltd. Feng Chan Village, Chang Xing Town Chongmin County Shanghai China |
|
Yard number |
H2363 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Bulkheads |
Transverse: 8 Longitudinal: 1 |
|
Main engine |
1x Wärtsilä 6L46C - 4 stroke 6 cylinder combustion engine 6.300 kW / 9.792 bhp at 500 rpm Builder: Wärtsilä Finland Oy |
|
Propellers |
1x Lips controllable pitch - 4 blades |
|
Boilers |
1x Auxiliary boiler, vertical shell type AQ-9 1x Auxiliary boiler, composite AQ-16 Builder: Aalborg Industries A/S |
|
Shaft generator |
1x AVK SDCT65 - 1.500 KW |
|
Generators |
2x Wärtsilä W4L20 diesel generatorset 600 kW 1x Wärtsilä W6L20 diesel generatorsets each 900 kW Total 2.400 kW at 900 rpm Builder: Wärtsilä Finland Oy |
|
Bow thruster |
1x Brunvoll 750 kW |
|
Number of cargo tanks |
12 |
|
Cargo capacity 98% |
18.491 m³ |
|
Number of slop tanks |
3 |
|
Slop tank capacity |
981 m³ |
|
Number of segregations |
8 |
|
Cargo pumps |
12x Framo centrifugal pumps each 300 m³/h 3x Framo centrifugal pumps each 150 m³/h 1x Framo centrifugal pumps 75 m³/h |
|
Pumping capacity |
2.100 m³/h |
|
Manifold |
Bow to centre manifold: 71,80 m |
|
Heating capacity |
70°C |
|
Tank capacities |
HFO: 580,0 m³ Diesel oil: 74,8 m³ Fresh water: 502,0 m³ Ballast: 8.179,3 m³ |
|
Anchor equipment |
Length: 577,5 m Diameter: 58 mm |
|
Lifting equipment |
1x Hose crane - SWL 5,0 t |
|
ISM & commercial manager |
Rederiet Stenersen A/S Solheimsgaten 13 5058 Bergen Norway |
|
Owner |
Stentank AS Solheimsgaten 13 5058 Bergen Norway |
|
Latest data adjustment |
29 January 2022 |
