Westerschelde 04 February 2016 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 04/02/16 | Westerschelde 08/08/18 | Westerschelde 15/08/19 | Westerschelde 18/03/20 | Westerschelde 11/06/18 | Westerschelde 19/08/15 | |||||
|
Name |
TRANS CHEMICA |
|
Previous names |
2005 - 2015 Stolt Jasmine |
|
Type |
Tanker for chemicals and oil products |
|
IMO-number |
9314715 |
|
Call sign |
9HA3947 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flags |
2005 - 2015 Republic of Panama, Panama City - Call sign: H3EM |
|
GT |
6.868 t |
|
DWT |
Summer: 12.430 t |
|
NT |
3.838 t |
|
Length |
123,22 m overall 115,85 m between perpendiculars |
|
Breadth |
20,00 m moulded |
|
Draught |
Summer: 8,75 m |
|
Moulded L x B x D |
115,85 x 20,00 x 11,20 m |
|
Registered L x B x D |
115,95 x 20,00 x 11,20 m |
|
Keel to mast end |
34,43 m |
|
Freeboard |
2.474 mm |
|
Depth |
11,20 m moulded |
|
Speed |
14,0 knots |
|
Built |
2005 |
|
Keel laid |
23/07/2004 |
|
Launch date |
29/09/2004 |
|
Date of completion |
11/01/2005 |
|
Builder |
Fukuoka Shipbuilding Co. Ltd. |
|
Yard number |
1238 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Akasaka/Mitsubishi 7UEC37LA - 2 stroke 7 cylinder 370 x 880 mm combustion engine 3.640 kW / 4.949 hp at 210,0 rpm Manufacturer: Akasaka Diesels Ltd. - Japan |
|
Propeller shaft |
1x Sea water lubrication shaft Diameter: 305 mm |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated 1x Auxiliary boiler, oil/gas fired |
|
Generators |
2x Yanmar 6N165L-EN main diesel generatorsets |
|
Bow thruster |
1x 446 kW |
|
Number of tanks |
18 + 2 slop tanks |
|
Cargo tank capacity |
13.572 m³ |
|
Number of segregations |
20 |
|
Number of pumps |
10x Cargo pumps each 300 m³/h 8x Cargo pumps each 200 m³/h |
|
Tank capacities |
Fuel oil: 774 m³ Water ballast: 3.402 m³ |
|
Anchor equipment |
Length: 522,50 m Diameter: 48 mm |
|
ISM & commercial manager |
Stödig Ship Management AS Wernersholmvegen 5 5232 Paradis Norway |
|
Owner |
Kjemikalietank AS Care of Seatrans AS Wernersholmvegen 5 5232 Paradis Norway |
|
Latest data adjustment |
13 September 2022 |
