Westerschelde 30 April 2016 |
 |
 |
 |
 |
|||
| Westerschelde 18/02/14 | Westerschelde 18/02/14 | Westerschelde 08/05/16 | Vlissingen 03/11/18 | |||
|
Name |
UGALE |
|
Type |
Tanker for oil & chemicals |
|
IMO-number |
9323352 |
|
Call sign |
V7LO3 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
GT |
30.641 t |
|
DWT |
Summer: 52.642 t |
|
NT |
15.308 t |
|
Length |
195,16 m overall 187,30 m between perpendiculars |
|
Breadth |
32,23 m extreme |
|
Draught |
Max.: 12,52 m |
|
Keel to mast end |
45,18 m |
|
Depth |
17,80 m moulded |
|
Speed |
Service: 14,0 knots |
|
Built |
2007 |
|
Keel laid |
19/08/2006 |
|
Launch date |
10/02/2007 |
|
Date of completion |
05/06/2007 |
|
Builder |
3 Maj Shipbuilding Industry (3. Maj Brodogradiliste d.d.) Rijeka Croatia |
|
Yard number |
699 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Wärtsilä 7RTA48T-B - 2 stroke 7 cylinder 480 x 2.000 mm combustion engine 10.185 kW / 13.848 hp at 127,0 rpm Builder: Wärtsilä Services Switzerland Ltd. |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated - KIP/DV-1.5/8 2x Auxiliary boiler, oil/gas fired - KLN/VIC-10/8 Builder: Saacke Marine Systems, Zagreb - Croatia |
|
Generators |
3x MAN 6L23/30H main diesel generatorsets |
|
Nuber of cargo tanks |
12 + 2 slop tanks |
|
Cargo tank capacity 98% |
56.150,70 m³ |
|
Slop tanks 98% |
1.348,3 m³ |
|
Total capacity 98% |
27.728,8 m³ |
|
Cargo pumps |
14x Hydraulic deepwell pumps: 12x Centrifugal pumps capacity 550 m³/h each 2x Centrifugal pumps capacity 300 m³/h each |
|
Tank capacities |
Fuel oil: 1.559,3 m³ Diesel oil: 183,6 m³ Ballast: 23.850,43 m³ |
|
Anchor equipment |
Length: 660,00 m Diameter: 76 mm |
|
Lifting equipment |
1x Crane - SWL 10,0 t |
|
Commercial manager |
LSC - Latvian Shipping Company Sporta iela 11 LV-1013 Riga Latvia |
|
ISM manager |
LSC Shipmanagement SIA Sporta iela 11 LV-1013 Riga Latvia |
|
Registered owner |
Sabile Navigation Inc. Care of JSC Latvian Shipping Co (Latvijas Kugnieciba), Sporta iela 11 LV-1013 Riga Latvia |
|
Renamed |
2023 Nari Srength Cook Islands, Avatiu - Call sign: E5U4875 Owner: Nebula Navigation Ltd. Manager: Peninsular Maritime India Pvt Ltd. |
|
Latest data adjustment |
10 December 2023 |
