Bochem Oslo - IMO 9420710

Westerschelde 23 May 2016

Name

BOCHEM OSLO

Previous names

2010 - 05.2013 JBU Oslo - from HAK Maritime S.A.

Type

Oil tanker / Chemical tanker

IMO-number

9420710

Call sign

3EWI5

Flag

Republic of Panama

Port of registry

Panama City

GT

19.910 t

Suez: 20.968,76 t

DWT

Summer: 33.654 t

NT

9.480 t

Suez: 19.298,28 t

Panama: 16.625 t

Length

170,17 m overall

162,00 m between perpendiculars

Breadth

26,60 m extreme

Draught

11,35 m

Keel to masthead

29,24 m

Air draft

Lightship: 36,63 m

Normal ballast: 31,21 m

At loaded summer deadweight: 27,87 m

Freeboard

Summer: 4.967 mm

Winter: 5.200 mm

Depth

16,30 m moulded

Speed

14,7 knots

Built

2010

Date of completion

29.01.2010

Builder

Kitanihon Shipbuilding Co. Ltd.
Hachinohe
Japan

Yard number

506

Hull material

Steel

Hull type

Double hull

Watertight compartments

9

Continuous decks

1

Main engine

1x AKASAKA / MHI - 2 stroke 6 cylinder 520 x 1.850 mm diesel engine- 7.980 kW / 10.842 hp at 120,0 rpm

Built: 04.09.2009

Builder: Akasaka Diesels Limited, Yaizu, Shizuoka - Japan

Propellers

1x Screw Propeller Solid - aft at 120,0 rpm

Boilers

1x CHR Miura Co., Ltd. 185,00 m² - 14,0 bar
2x CHO Miura Co., Ltd. 115,50 m² - 9,0 bar

Generators

3x Diesel generatorsets each 763 kVA - 610 kW - 897 hp

Emergency generator

1x Diesel generatorset 100 kVA - 80 kW - 143 hp

Number of cargo tanks

14

Cargo tank capacities 98%

Seg#1: 5.254,831 m³ (P & S)
Seg#2: 5.685,580 m³ (P & S)
Seg#3: 4.821,415 m³ (P & S)
Seg#4: 5.553,404 m³ (P & S)
Seg#5: 2.629,224 m³ (P & S)
Seg#6: 5.307,079 m³ (P & S)
Seg#7: 5.226,660 m³ (P & S)

Total: 34.478,193 m³ excluding slop tanks

Number of slop tanks

2

Slop tank capacity 98%

2.686,717 m³

Max. loading rate per manifold

476 m³/h

Pumps

Cargo pumps:

14x Centrifugal each 330 m³/h

2x Centrifugal each 220 m³/h

Ballast pumps:

2x Framo SB 200T each 500 m³/h

Manifolds

Bow to centre manifold: 83,37 m

Stern to centre manifold: 86,80 m

Distance bridge front to centre of manifold: 60,75 m

Distance between cargo manifold centres: 500 mm

Distance ships rail to manifold: 5.540 mm

Distance manifold to ships side: 5.790 mm

Top of rail to centre of manifold: 5.540 mm

Distance main deck to centre of manifold: 3.450 mm

Bunker capacity

Fuel oil: 1.695,39 m³

Gas oil: 254,86 m³

Lifting equipment

1x Crane - SWL 10,0 t

Maximum outreach of cranes: 4,90 m

Technical operator

Fleet Management Ltd.
11/F Dah Sing Financial Center

108, Gloucester Rd

Wanchai

Hong Kong

Commercial operator

Hansa Tankers AS
Hansa Tankers AS Kalfarveien 57a
5022 Bergen
Norway

Disponent owner

CMB NV
De Gerlachekaai, 20
BE-2000 Antwerpen
Belgium

Registered owner

Hak Maritime, S.A.
53rd Street, Urbanizacion, Merbella, MMG Tower
16th Floor
Panama
Republic of Panama

Latest data adjustment

13 February 2015
