Westerschelde 21 September 2013 |
 |
 |
 |
||
| Westerschelde 21/09/13 | Westerschelde 03/06/15 | Westerschelde 18/09/15 | ||
|
Name |
NORDIC TRINE |
|
Previous names |
2007 Launch as: Marsel 11/2007 - 08/2013 Trine Theresa |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9388479 |
|
Call sign |
9HFZ9 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
5.289 t |
|
DWT |
Summer: 7.914,94 t |
|
NT |
2.415 t |
|
Length |
122,66 m overall 115,31 m between perpendiculars |
|
Breadth |
17,20 m |
|
Draught |
6,85 m |
|
Air draft |
30,75 m |
|
Freeboard |
1.952 mm |
|
Depth |
8,80 m |
|
Speed |
14,0 knots |
|
Built |
2007 |
|
Date of completion |
26/11/2007 |
|
Builder |
Yildirim Shipyard AS Istanbul Turkey |
|
Yard number |
109 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MaK 8M32C - 4 stroke single acting 8 cylinder 320 x 480 mm combustion engine 4.000 kW / 5.438 hp at 600 rpm Builder: Caterpillar MaK Motoren GmbH & Co., KG |
|
Propellers |
1x Screw propeller controllable pitch |
|
Boilers |
1x CHR 71,00 m² - 10,0 bar 2x CHO 57,00 m² - 13,0 bar 1x CHR 80,00 m² - 8,0 bar |
|
Generators |
3x MAN main diesel generatorsets each 750 kVA - 595 kW - 815 hp / 450 Volt 60 Hz |
|
Emergency generator |
1x MAN diesel generatorset 110 KW |
|
Bow thruster |
1x Tunnel thruster 450 kW / 612 bhp, forward |
|
Number of cargo tanks |
13 |
|
Segregations |
14 |
|
Cargo capacity 98% |
8.493,12 m³ + 2x 49 m³ in 2 deck slop tanks |
|
Pumps |
12x Deepwell pumps each 30 m³/h 1x Deepwell pumps 100 m³/h 1x Centrifugal pump 50 m³/h |
|
Loading rate |
360 m³/h per tank - 150 m³/h cargo tk no 1 |
|
Heating capacity |
2.000 KW |
|
Tank cleaning system |
26x Scanjed fixed BW machines - 2x 2.000 kW heater |
|
Tank capacities |
Fuel oil: 427 m³ Diesel oil: 79 m³ Ballast water: 3.640 m³ |
|
Crew size |
15 |
|
Lifting equipment |
1x Crane - SWL 3,0 t at 15,00 m |
|
Manager |
Nordic Tankers Marine AS Sundkrogsgade 21 Copenhagen Denmark |
|
Previous manager |
11/2007 - 08/2013 Bernard Schulte Shipmanagement, Limassol - Cyprus |
|
Operator |
Nordic Tankers Marine AS |
|
Registered owner |
Harbour Shipowning Aps. Copenhagen Denmark |
|
Previous names & owners |
11/2007 - 08/2013 Trine Theresa - Trine Theresa K.S., Copenhagen - Denmark |
|
Renamed |
12/2015 Thun Greenwich The Netherlands, Delfzijl - Call sign: PDDY Manager: Marin Ship Management B.V., Farmsum - The Netherlands Owner: Thun Tankers B.V., Delfzijl - The Netherlands 2021 Fortuna I 12/2021 - 05/2002 United Kingdom , Londen - Call sign: MKPR8 05/2002 Belgium, Zeebrugge - Call sign: ONLG Manager: V Ships UK Ltd., London - United Kingdom Owner: Prax Shipping I B.V. - Belgium |
|
Latest data adjustment |
22 May 2014 |
