Westerschelde 03 April 2014 |
 |
 |
|
| Westerschelde 03/04/14 | Westerschelde 03/04/14 | |
|
Name |
BUNGA BALSEM |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9458822 |
|
Call sign |
9MLH8 |
|
Flag |
Malaysia |
|
Port of registry |
Port Klang |
|
GT |
29.124 t registered Suez: 30.644,91 t |
|
DWT |
Summer: 45.612,2 t |
|
NT |
11.608 t registered Panama: 24.763 t Suez: 26.236,82 t |
|
Length |
183,00 m overall 174,00 m between perpendiculars |
|
Breadth |
30,20 m |
|
Draught |
11,20 m |
|
Freeboard |
6.764 mm |
|
Depth |
18,90 m moulded |
|
Speed |
Max.: 14,6 knots Service: 14,1 knots |
|
Built |
2010 |
|
Keel laid |
26.11.2009 |
|
Launch date |
27.01.2010 |
|
Date of completion |
30.09.2010 |
|
Builder |
Shinasb Yard Co., Ltd. Tongyoung |
|
Yard number |
S522 |
|
Hull material |
High strength steel Ordinary strength steel |
|
Hull type |
Double hull |
|
Bulkheads |
Water tight: 8 Oil tight: 12 |
|
Main engine |
1x MAN B&W 6S50MC-C7 - 6 cylinder 500 x 2.000 mm diesel engine - 9.480 kW at 127,0 rpm Manufacturer: HHI Engine & Machinery Div. |
|
Propellers |
1x Fixed Pitch Propeller Manufacturer: HHI Engine & Machinery Div. |
|
Generators |
1x Cummins UCM274F1 diesel generatorset 120 kW Manufacturer: Cummins Generator Technologies 3x HFC7 504-84K diesel generatorsets each 757 kW Manufacturer: HHI Electro Electric System |
|
Number of cargo tanks |
22 |
|
Cargo oil tank capacity |
53.502,20 m³ / 52.432,15 t |
|
Number of tanks |
Ballast: 12 Lubricating oil: 9 Fuel oil: 8 Diesel oil: 4 Fresh water: 3 Gasoline: 2 Sludge: 2 Chain: 2 Waste water: 1 |
|
Tank capacities |
Diesel Oil: 247,5 m³ / 211,02 t Freshwater: 297,9 m³ Fuel Oil: 1.571,9 m³ / 1.540,46 t Lube Oil: 133,9 m³ / 120,51 t Tank Ballast: 22.729 m³ / 23.297,22 t |
|
Lifting equipment |
2x Elec. provision crane DN09-12-29P - SWL 3,0 t 1x Engine room crane DN09-11-29 - SWL 2,5 t 1x Hose handling crane DN09-12-25 - SWL 10,0 t Manufacturer: Dongnam Marine Crane Co., Ltd. |
|
Manager |
MISC Berhad |
|
Registered owner |
Malaysian International Shpg. Corp. Berhad |
|
Latest data adjustment |
16 April 2014 |
