| Antwerpen 04 May 2014 |
 |
| Antwerpen 05/07/13 |
|
Name |
KRISTIN KNUTSEN |
|
Type |
Tanker for chemicals |
|
IMO-number |
9141405 |
|
Call sign |
LAGR5 |
|
Flag |
Norway |
|
Port of registry |
Haugesund |
|
GT |
12.184 t |
|
DWT |
19.110 t |
|
NT |
5.667 t |
|
Length |
148,43 m overall 139,30 m between perpendiculars |
|
Breadth |
23,00 m |
|
Draught |
9,95 m |
|
Keel to Masthead |
38,00 m |
|
Freeboard |
Summer: 3.012 mm Winter: 3.219 mm Tropical: 2.780 |
|
Depth |
12,95 m |
|
Speed |
15,0 knots |
|
Built |
1998 |
|
Date of completion |
23.03.1998 |
|
Builder |
Naval Gijon, S.A.U. |
|
Yard number |
550 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN B&M 5S50MC - 7.139 kW |
|
Propellers |
1x Controllable pitch |
|
Generators |
3x 5L23/30H B&W Holeby each 890 bhp diesel generatorsets |
|
Bow thruster |
1x 800 bhp / 596,56 kW |
|
Total cubic capacity 98% |
19.409 m³ excluding slop tanks |
|
Maximum loading rate |
2.000 m³/h |
|
Pumps |
34x Cargo centrifugal cargo pumps each 230 m³/h 2x Centrifugal ballast pumps each 500 m³/h |
|
Manifolds |
Bow to centre Manifold: 70,60 m Stern to centre Manifold: 77,83 m Distance bridge front to centre of manifold: 47,40 m Distance between cargo manifold centres: 550 mm Distance ships rail to manifold: 4.900 mm Distance manifold to ships side: 4.950 mm Top of rail to centre of manifold: 1.225 mm Distance main deck to centre of manifold: 3.020 mm |
|
Tank capacities |
Fuel oil: 1.196,9 m³ Diesel oil: 91,9 m³ |
|
Lifting equipment |
2x Cranes - each SWL 10,0 t |
|
Manager |
Knutsen OAS Shipping AS |
|
Operator commercial |
Atlas Chemical Tankers ( Bergen ) Frydenbolien 19, NO-5056 Bergen, 2nd Floor P.O. Box 864 Sentrum, NO-5807 Bergen Norway |
|
Owner |
Knutsen Kjemikalie Tanker III KS |
|
Registered owner |
Knutsen Kjemikalie Tanker III KS c/o Knutsen OAS Shipping AS 5501 Haugesund |
|
Last update |
04 August 2013 |
