| Antwerpen 27 May 2013 |
|
Name |
NOVUM |
|
Type |
Inland tanker |
|
ENI-number |
02329409 |
|
Call sign |
PD2363 |
|
Flag |
The Netherlands |
|
Port of registry |
Kampen |
|
GT |
1.116 t |
|
DWT |
1.540 t |
|
Length |
85,97 m overall 83,03 m between perpendiculars |
|
Breadth |
9,64 m |
|
Draught |
3,20 m |
|
Depth |
4,56 m |
|
Built |
2007 |
|
Date of completion |
01.11.2007 |
|
Builder casco |
Chvaletice Shipyard |
|
Builder completion |
Bijlsma Shipyard |
|
Yard number |
18 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x MTU 8V 4000 M60 - 4 stroke 8 cylinder 165 x 190 mm diesel engine - 850 kW / 1.156 hp at 1.800 rpm Built: 2006 Builder: MTU Friedrichshafen GmbH, Friedrichshafen - Germany |
|
Gearbox |
1x Masson ZF / Masson W4400 - reduction 5.542:1 |
|
Propellers |
1x Screw propeller solid 5-blades diameter 1.650 mm with nozzle type Van de Giessen Optima diameter 1.662 mm |
|
Generators |
1x Cummins N14 engine - 336 kW coupled with Marathon 433 PSL 6216 generator - 420 kVA 1x Cummins 6BT 5.9 G6 engine - 148 kW coupled with Marathon 431 PSL 6202 generator - 111 kVA 1x Cummins 4BT 3.9 G4 - 53 kW engine coupled with Marathon 362 PSL 1604 generator - 63 kVA |
|
Bow thruster |
1x Cummins-van Wijk - 400 hp |
|
Cargo tank capacity |
1.825 m³ |
|
Number of tanks |
5 |
|
Number of pumps |
5x Pumps each 100 m³/h |
|
Owner |
Mika BV |
|
Last update |
03 July 2013 |
