| Gibraltar 21 September 2011 |
|
Name |
VEMAOIL XIV |
|
Previous names |
1993 - 28.05.2009 Sohwa Maru No.5 28.05.2009 - 26.10.2010 Orange Sun |
|
Type |
Oil / Chemical carrier - Tanker in use as bunkering tanker |
|
IMO-number |
9078414 |
|
Call sign |
9HA2016 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
2.992 t |
|
DWT |
4.825 t |
|
NT |
1.267 t |
|
Length |
105,00 m |
|
Breadth |
15,20 m |
|
Draught |
Summer: 6,485 m |
|
Moulded L x B x D |
97,00 x 15,20 x 7,50 m |
|
Registered L x B x D |
97,00 x 15,20 x 7,50 m |
|
Keel to masthead |
29,00 m |
|
Freeboard |
Summer: 1.043 mm |
|
Depth |
7,50 m moulded |
|
Speed |
Trial: 14,4 knots |
|
Built |
1993 |
|
Keel laid |
31.05.1993 |
|
Launch date |
02.07.1993 |
|
Date of completion |
08.09.1993 |
|
Builder |
Kurinoura Dockyard & Shipbuilding Co., Ltd. |
|
Yard number |
310 |
|
Hull type |
Double hull |
|
Main engine |
1x HANSHIN 6LF50A-220 6C - 4 stroke single acting 6 cylinder 500 x 800 mm diesel engine - 2.942 kW at 230,0 rpm Manufacturer: The Hanshin Diesel Works, Ltd. |
|
Number of propellers |
1 |
|
Propeller shaft |
1x Sea water lubrication shaft |
|
Boilers |
1x Auxiliary boiler - 4,9 bar Evaporation: 522,0 kW Manufacturer: Miura Co., Ltd. 1x Auxiliary boiler - 7,0 bar Evaporation: 300,0 kW Manufacturer: JiangYin Sanjie Industry Co., Ltd. |
|
Generators |
4x Diesel generatorsets - 1,050 kVA |
|
Number of tanks |
10 |
|
Tank capacity 98% |
Number 1: 651,189 m³ port- and starboard side Number 2: 1.001,52 m³ Number 3: 1.020,646 m³ Number: 1.018,702 m³ Slops 1: 424,718 m³ Slops 2: 427,164 m³ |
|
Total tank capacity 98% |
4.543,939 m³ |
|
Slop tanks cap. 98% |
851,882 m³ |
|
Cargo pumps |
2x Type screw each 1.500 m³/h 1x Type gear 95 m³/h 1x Type screw 30 m³/h |
|
Ballast pumps |
2x Centrifugal: 1x 400 m³/h 1x 200 m³/h |
|
Manifolds |
Bow to centre Manifold: 56,00 m Stern to centre Manifold: 49,00 m Distance bridge front to centre of manifold: 23,00 m Distance ships rail to manifold: 2.850 mm Distance manifold to ships side: 3.100 mm Top of rail to centre of manifold: 850 mm Distance main deck to centre of manifold: 1.800 mm |
|
Maximum loading rate |
900 m³/h |
|
Tank capacities |
Fuel oil: 264 m³ Fresh water: 140 m³ Water ballast: 1.259 m³ |
|
Manager |
Queensway Navigation Co., Ltd. |
|
Operator |
Queensway Navigation Co. Ltd. 1, Alexandrou Pantou & Kallirois Str. 176 71 Athens |
|
Owner |
Queensway Navigation |
|
Registered owner |
Navamar Marine Corp Trust Company Complex Ajeltake Road-Ajeltake Island Majuro |
