| Westerschelde 23 January 2012 |
 |
 |
 |
 |
|||
| Westerschelde 23/01/12 | Westerschelde 14/05/12 | Westerschelde 22/05/14 | Westerschelde 04/06/15 | |||
|
Name |
THEODORA |
|
Type |
Bitumen / Oil products tanker |
|
IMO-number |
9005338 |
|
Call sign |
PHYG |
|
Flag |
The Netherlands |
|
Port of registry |
Rotterdam |
|
GT |
4.098 t |
|
DWT |
6.616 t |
|
NT |
1.460 t |
|
Length |
110,60 m overall 103,30 m between perpendiculars |
|
Breadth |
17,00 m |
|
Draught |
7,06 m |
|
Freeboard |
2.320 mm |
|
Depth |
9,36 m |
|
Speed |
14,0 knots |
|
Built |
1991 |
|
Keel laid |
07/01/1990 |
|
Launch date |
03/09/1991 |
|
Date of completion |
12/04/1991 |
|
Builder |
IHC Merwede Scheepswerf B.V. Hardinxveld Giessendam The Netherlands |
|
Yard number |
658 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
7 |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 8R32E - 4 stroke single acting 8 cylinder 320 x 350 mm combustion engine 3.000 kW / 4.076 hp at 750 rpm Built: 1990 Manufacturer: Wärtsilä Diesel Oy, Vaasa/Vasa - Finland |
|
Propellers |
1x Screw propeller controllable pitch at 157 rpm |
|
Electrical installations |
Power voltage: 380 V Lighting voltage: 220 V Frequency: 50 Hz |
|
Diesel generators |
4x Volvo Penta TMD 122 A/KC diesel generatorsets each 250 kVA - 200 kW at 1.500 rpm |
|
Compressed air receivers |
Auxiliary machinery: 4 x Volvo Penta TMD 122 A/KC - 215 kW at 1.500 rpm |
|
Bow thruster |
1x Jastram BU40-F - 275 kW |
|
Number of tanks |
9 6x Wing tanks 3x Centre tanks |
|
Total cap. of tanks 98% |
5.156 m³ |
|
Cargo handling |
3x Bornemann screw cargo pumps with a capacity of 375 m³/h each |
|
Cargo heating |
Maximum cargo temperature 250ºC 2x Wiesloch 08-V2-25 thermal oil boiler |
|
Manifold |
Bow to centre manifold: 52,40 m |
|
Fuel capacity |
446 m³ |
|
Manager |
Tarbit Tankers BV Wolwevershaven 30 3300 AP Dordrecht The Netherlands |
|
Previous managers |
1991 - 2007 Rederij Theodora B.V., Rotterdam - The Netherlands |
|
Registered owner |
Bulgersteyn BV Wolwevershaven 30-M 3311AW Dordrecht The Netherlands |
|
Previous names & owners |
1991 - 2001 Theodora - Scheepvaart Maatschappij Castor B.V., Rotterdam - The Netherlands |
|
Renamed |
08/2018 Global Asphalt Republic of Panama, Panama City - Call sign: 3FZQ3 Owner: Asphalt Shipping Lines Inc., Chandigarh - India Manager: Global Tankers Pvt Ltd., Chandigarh - India |
|
Latest data adjustment |
12 March 2024 |
