| Westerschelde 07 October 2015 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 07/10/15 | Westerschelde 07/10/15 | Westerschelde 25/09/12 | Westerschelde 25/09/12 | Antwerpen 18/05/14 | Antwerpen 23/05/19 | |||||
|
Name |
SICHEM PALACE |
|
Type |
Oil / Chemical carrier |
|
IMO-number |
9304318 |
|
Call sign |
9HA3856 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flag |
2004 - 2015 Republic of Singapore, Singapore City - Call sing: S6AV8 |
|
GT |
5.451 t registered |
|
DWT |
Summer: 8.807,02 t |
|
NT |
2.640 t registered |
|
Displacement |
11.584 t |
|
Length |
112,02 m overall 105,00 m between perpendiculars |
|
Breadth |
19,00 m extreme |
|
Draught |
7,56 m |
|
Moulded L x B x D |
105,00 x 19,00 x 10,00 m |
|
Registered L x B x D |
105,32 x 19,00 x 10,00 m |
|
Keel to masthead |
31,85 m |
|
Air draft |
Lightship: 27,92 m Normal ballast: 27,40 m At loaded summer deadweight: 24,28 m |
|
Freeboard |
2.462 mm |
|
Depth |
10,00 m moulded |
|
Speed |
Service: 14,0 knots Max.: 16,3 knots |
|
Built |
2004 |
|
Keel laid |
21.04.2004 |
|
Launch date |
20.07.2004 |
|
Date of completion |
29.09.2004 |
|
Builder |
Usuki Shipyard Co., Ltd. |
|
Yard number |
1688 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN-B&W/Makita 6L35MC - 2 stroke single acting 6 cylinder 350 x 1.050 mm diesel engine - 3.900 kW at 210,0 rpm Manufacturer: Makita Corporation |
|
Propellers |
1 |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device |
|
Boilers |
1x Auxiliary oil/gas vertical boiler - 8,8 bar Evaporation: 10,67 t/h Manufacturer: Tortoise Engineering Co., Ltd. 1x Auxiliary boiler, exhaust gas heated |
|
Generators |
2x Daihatsu 5DC-17 diesel generatorsets each Builder: Daihatsu Diesel Mfg. Co., Ltd. Moriyama Factory |
|
Emergency generator |
1x Deutz F5l912 diesel generatorset |
|
Bow thruster |
1x 335 kW |
|
Number of cargo tanks |
10x Cargo tanks 1-5 port/starboard + 2x slops port/ starboard |
|
Cargo tank capacity 98% |
Liquid: 9.244,93 m³ |
|
Slop tanks 98% |
507,720 m³ |
|
Manifolds |
Bow to centre manifold: 47,70 m Stern to centre manifold: 64,30 m Distance bridge front to centre of manifold: 34,30 m Distance between cargo manifold centres: 800 mm Distance ships rail to manifold: 2.906 mm Distance manifold to ships side: 3.100 mm Top of rail to centre of manifold: 900 mm Distance main deck to centre of manifold: 2.397 mm |
|
Pumps |
12x Cargo pumps each 250 m³/h 1x Ballast pump 300 m³/h |
|
Tank capacities |
Fuel oil: 706 m² Fresh water: 171 m³ Water ballast: 2.762 m³ |
|
Anchor equipment |
Length: 495,00 m Diameter: 50 mm |
|
Lifting equipment |
1x Cranes - SWL 5,0 t |
|
Commercial manager |
Team Tankers International |
|
Technical manager |
V.Ships France |
|
Previous manager |
Thome Ship Management Pte., Ltd. - Republic of Singapore |
|
Owner |
Team Tankers Regional Ltd. |
|
Latest data adjustment |
18 April 2017 |
