Name |
JANNE WONSILD |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9010931 |
|
Call sign |
ICWB |
|
Flag |
Italy |
|
Port of registry |
Augusta |
|
GT |
2.349 t |
|
DWT |
2.694 t |
|
NT |
816 t |
|
Length |
89,60 m overall 80,90 m between perpendiculars |
|
Breadth |
14,00 m |
|
Draught |
5,21 m |
|
Freeboard |
1.361 mm |
|
Depth |
6,55 m |
|
Speed |
13,5 knots |
|
Built |
1993 |
|
Keel laid |
20.09.1989 |
|
Launch date |
25.07.1992 |
|
Date of completion |
12.07.1993 |
|
Builder |
Societa' Esercizio Cantieri S.P.A. |
|
Yard number |
785 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
10 |
|
Continuous decks |
1 |
|
Main engine |
1x Yanmar 6N330-EN- 4 stroke 6 cylinder diesel engine - 2.208 kW / 3.000 hp at 620 rpm Built: 1991 Builder: Yanmar Co., Ltd. Amagasaki Plant, Amagasaki - Japan |
|
Propellers |
1x Screw propeller controllable pitch - at 184 rpm |
|
Boilers |
2x Thermal oil fired - 1.744 kW/h 1x Thermal exhaust gas - 465 kW/h |
|
Shaft generator |
1x 812 kVA |
|
Generators |
1x 6 cylinder diesel generatorset 313 kVA - 250 kW - 611 hp |
|
Emergency generator |
1x Diesel generatorset 44 kVA - 35 kW - 60 hp |
|
Bow thruster |
400 kW |
|
Number of cargo tanks |
14 |
|
Total capacity of tanks 98% |
2.966 m³ |
|
Cargo pumps |
14x Pumps each 150 m³/h |
|
Ballast pumps |
2x 250 t/h each |
|
Manifolds |
Distance from bow: 46,95 m Distance form stern: 42,30 m Height above deck: 3,230 m / 3,196 m Distance inboard: 2,760 m Distance between manifolds: 0,80 m |
|
Fuel oil |
Bunker cap. 98%: 290 t |
|
Lifting equipment |
1x Hose crane- SWL 3,0 t at 10,00 m |
|
Manager |
Nordic Tankers A/S |
|
Owner |
Etnea Marittima |
|
Registered owner |
Marittima Etnea S.R.L. |
|
Last update |
05.04.2013 |
